Sony CDX-M3DI - Lever Section; Servo Board

14
CDX-M3DI/M1000TF
2-10. SERVO BOARD
2-9. LEVER SECTION
4 two claws
1 special screw
7 lever (L)
6 lever (R)
3 tension spring (LR)
2 DISC IN SW board
5 guide (disc)
1 CN3
3 Removal the solders.
7 special screws
8 special screw
2 CN2
optical pick-up block
9 SERVO board
5 P2x3
6 loading motor assy
4 Unsolder the
lead wires.
black
yellow
