Sony CDX-M3DI - Circuit Boards Location

25 25
CDX-M3DI/M1000TF
SERVO board
MAIN board
LIMIT SW boar
d
LOAD SW board
DISC IN SW board
DIGITAL board
DISPLAY board
SWITCH board
4-5. CIRCUIT BOARDS LOCATION
— Main Board —
1
2
32.768kHz
IC501
uf
(X0A)
4.332MHz
IC201
4
(OSCO)
4.8Vp-p
3
3.6864MHz
IC501
os
(X0)
4
4MHz
IC605
4
(XOUT)
3Vp-p
3.6Vp-p
4.3Vp-p
Note:
The components identi-
fied by mark 0 or dotted
line with mark 0 are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
THIS NOTE IS COMMON FOR PRINTED WIRING
BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is
printed in each block.)
for schematic diagram:
• All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
• All resistors are in Ω and
1
/
4
W or less unless otherwise
specified.
•%: indicates tolerance.
•
f
: internal component.
• C : panel designation.
• A : B+ Line.
• Power voltage is dc 14.4V and fed with regulated dc power
supply from ACC and BATT cords.
•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
• Circled numbers refer to waveforms.
• Signal path.
F : FM
f : AM (MW/LW)
J : CD
c : CD-R/RW (MP3)
for printed wiring boards:
• X : parts extracted from the component side.
• Y : parts extracted from the conductor side.
•
a
: Through hole.
• : Pattern from the side which enables seeing.
(The other layer’s patterns are not indicated.)
Caution:
Pattern face side: Parts on the pattern face side seen from the
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.
• Waveforms
— Servo Board —
(MODE: CD PLAY)
2
IC1
uj
(RFO)
1.7Vp-p
3
Approx. 200mVp-p
IC1
oa
(FEO)
0V
4
Approx. 300mVp-p
IC1
od
(TEO)
0V
5
1
2.8Vp-p
12.288MHz
IC3
yd
(XTAL)
16.9344MHz
IC1
wd
(XTAL)
1.2Vp-p
