49
CDX-M3DI/M1000TF
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
A-3337-599-A DIGITAL BOARD, COMPLETE
(When repairing, the complete DIGITAL
board should be replaced since
any parts in the DIGITAL board
cannot be repaired.)
***********************
*************************************************************
A-3274-253-A DISC IN SW BOARD, COMPLETE
**************************
*************************************************************
A-3337-604-A DISPLAY BOARD, COMPLETE
************************
3-241-870-02 PLATE (PANEL), SHIELD
7-685-132-19 SCREW +P 2.6X5 TYPE2 NON-SLIT
< CAPACITOR >
C200 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C201 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C202 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C203 1-131-618-21 ELECT CHIP 22uF 20% 12.5V
C204 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C205 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C206 1-164-346-11 CERAMIC CHIP 1uF 16V
C207 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C208 1-162-922-11 CERAMIC CHIP 39PF 5% 50V
C209 1-164-346-11 CERAMIC CHIP 1uF 16V
C210 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C211 1-131-618-21 ELECT CHIP 22uF 20% 12.5V
C212 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C213 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C214 1-137-988-11 CERAMIC CHIP 1uF 10% 35V
C215 1-137-988-11 CERAMIC CHIP 1uF 10% 35V
C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C217 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C218 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C219 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C220 1-100-009-11 FILM CHIP 0.082uF 5% 50V
C221 1-125-889-11 CERAMIC CHIP 2.2uF 10% 10V
C222 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C223 1-137-988-11 CERAMIC CHIP 1uF 10% 35V
C224 1-127-692-11 CERAMIC CHIP 10uF 10% 6.3V
C225 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C226 1-137-988-11 CERAMIC CHIP 1uF 10% 35V
C227 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C228 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C229 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C230 1-117-863-11 CERAMIC CHIP 0.47uF 10% 6.3V
C231 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C232 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C233 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C234 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C235 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C236 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C237 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C238 1-165-955-21 ELECT CHIP 8.2uF 20% 16V
C239 1-135-405-11 CERAMIC CHIP 10uF 10% 25V
C240 1-127-692-11 CERAMIC CHIP 10uF 10% 16V
C244 1-115-566-11 CERAMIC CHIP 4.7uF 10% 10V
C245 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C246 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C247 1-135-405-11 CERAMIC CHIP 10uF 10% 25V
C248 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C249 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C250 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C251 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C252 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C253 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C254 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C255 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C256 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
< CONNECTOR >
* CN200 1-766-311-21 PIN, CONNECTOR (PC BOARD) 2P
CN201 1-816-467-11 CONNECTOR, FPC (ZIF) 51P
CN202 1-816-485-21 CONNECTOR, FFC/FPC (ZIF) 50P
< DIODE >
D200 8-719-977-12 DIODE DTZ6.8B
D201 8-719-080-04 LED CL-190UB-X-T (OFF)
D202 8-719-080-04 LED CL-190UB-X-T (SOURCE)
D203 8-719-080-04 LED CL-190UB-X-T (Z)
D204 8-719-080-04 LED CL-190UB-X-T (SCREEN)
D207 8-719-404-50 DIODE MA111-TX
D208 8-719-080-04 LED CL-190UB-X-T (MODE)
D210 6-500-219-01 DIODE 1SS404(TPH3)
D211 6-500-219-01 DIODE 1SS404(TPH3)
D212 8-719-404-50 DIODE MA111-TX
D213 8-719-977-12 DIODE DTZ6.8B
DISPLAY
DISC IN SWDIGITAL
