51
CDX-M3DI/M1000TF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
< VARIABLE RESISTOR >
RV402 1-238-090-11 RES, ADJ, CERMET 10K
< SWITCH >
S200 1-771-884-31 SWITCH, TACTILE (WITH LED) (OFF)
S201 1-771-884-31 SWITCH, TACTILE (WITH LED) (Z)
S202 1-771-027-21 SWITCH, KEYBOARD (LED NON) (SOURCE)
S203 1-771-884-31 SWITCH, TACTILE (WITH LED) (MODE)
S204 1-786-355-21 SWITCH, TACTILE (WITH LED) (VOL +)
S205 1-786-355-21 SWITCH, TACTILE (WITH LED) (VOL –)
S206 1-786-355-21 SWITCH, TACTILE (WITH LED) (.)
S207 1-786-355-21 SWITCH, TACTILE (WITH LED) (>)
S208 1-771-884-31 SWITCH, TACTILE (WITH LED) (SHIFT)
S209 1-771-884-31 SWITCH, TACTILE (WITH LED) (RESET)
S210 1-771-027-21 SWITCH, KEYBOARD (LED NON) (SCREEN)
< TRANSFORMER >
T200 1-437-741-11 TRANSFORMER, DC-AC CONVERTER
< THERMISTOR >
TH200 1-810-812-21 THERMISTOR, NTC (1608)
*************************************************************
A-3274-254-A LIMIT SW BOARD, COMPLETE
*************************
< CONNECTOR >
CN13 1-816-275-21 CONNECTOR, FFC/FPC 6P
*************************************************************
1-685-337-11 LOAD SW BOARD
***************
*************************************************************
A-3274-820-A MAIN BOARD, COMPLETE (M1000TF)
A-3337-600-A MAIN BOARD, COMPLETE (M3DI)
*********************
X-3383-743-1 CORD (ANT) ASSY (ANTENNA)
1-694-592-31 TERMINAL
1-827-121-11 CORD, CONNECTION (AUDIO OUT FRONT/REAR)
* 3-019-565-01 BRACKET (IC)
3-041-261-11 BRACKET (TR)
3-564-708-01 SCREW (+P 2X18) (TYPE2)
7-685-790-09 SCREW +PTT 2.6X4 (S)
7-685-792-09 SCREW +PTT 2.6X6 (S)
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< BUZZER >
BZ901 1-544-886-11 BUZZER
< CAPACITOR >
C102 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C104 1-135-346-21 ELECT CHIP 39uF 20% 16V
C105 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C106 1-137-765-21 ELECT CHIP 47uF 20% 16V
C107 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C108 1-115-156-11 CERAMIC CHIP 1uF 10V
C109 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C110 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C112 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C113 1-135-346-21 ELECT CHIP 39uF 20% 16V
C114 1-137-765-21 ELECT CHIP 47uF 20% 16V
C116 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C117 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C118 1-117-681-11 ELECT CHIP 100uF 20% 16V
C119 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C120 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C122 1-115-156-11 CERAMIC CHIP 1uF 10V
C123 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C125 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C126 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C127 1-104-607-11 ELECT CHIP 47uF 20% 16V
C128 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C130 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C131 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C132 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C133 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C134 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C135 1-135-346-21 ELECT CHIP 39uF 20% 16V
C136 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C137 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C138 1-115-156-11 CERAMIC CHIP 1uF 10V
C139 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C140 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C141 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C142 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C143 1-137-765-21 ELECT CHIP 47uF 20% 16V
C145 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C146 1-135-346-21 ELECT CHIP 39uF 20% 16V
C147 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C148 1-137-765-21 ELECT CHIP 47uF 20% 16V
C149 1-125-701-11 DOUBLE LAYERS 0.047F 5.5V
C150 1-126-916-11 ELECT 1000uF 20% 6.3V
C151 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C152 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C153 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C154 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C172 1-104-951-11 ELECT 10uF 20% 16V
C182 1-124-233-11 ELECT 10uF 20% 16V
C201 1-124-589-11 ELECT 47uF 20% 16V
(M1000TF)
C202 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(M1000TF)
C203 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(M1000TF)
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
(M1000TF)
C206 1-124-259-11 ELECT 4.7uF 20% 16V
(M1000TF)
C207 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
(M1000TF)
C208 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
(M1000TF)
C209 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
DISPLAY LIMIT SW LOAD SW
To Next Page
