Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CFD-CD777SMK2
56
AMP BATTERY CONTROL DC JACK
R380 1-212-934-00 FUSIBLE 1 5% 1/2W
R388 1-249-415-11 CARBON 680 5% 1/4W
R389 1-249-417-11 CARBON 1K 5% 1/4W
R410 1-249-415-11 CARBON 680 5% 1/4W
************************************************************
* 1-670-300-11 BATTERY BOARD
**************
< CONNECTOR >
CNP902 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
************************************************************
* A-3321-420-A CONTROL BOARD, COMPLETE
*************************
3-022-867-01 HOLDER, LCD
3-022-868-01 HOLDER (LARGE), LED
< CAPACITOR >
C128 1-162-851-11 CERAMIC 0.1uF 10% 16V
C129 1-126-964-11 ELECT 10uF 20% 50V
C141 1-126-947-11 ELECT 47uF 20% 35V
C142 1-104-665-11 ELECT 100uF 20% 25V
C228 1-162-851-11 CERAMIC 0.1uF 10% 16V
C229 1-126-964-11 ELECT 10uF 20% 50V
C241 1-126-947-11 ELECT 47uF 20% 35V
C242 1-104-665-11 ELECT 100uF 20% 25V
C800 1-126-947-11 ELECT 47uF 20% 35V
C803 1-126-947-11 ELECT 47uF 20% 35V
C804 1-126-964-11 ELECT 10uF 20% 50V
C805 1-162-306-11 CERAMIC 0.01uF 20% 16V
C807 1-162-306-11 CERAMIC 0.01uF 20% 16V
C809 1-162-306-11 CERAMIC 0.01uF 20% 16V
C810 1-162-294-31 CERAMIC 0.001uF 10% 50V
C876 1-162-282-31 CERAMIC 100PF 10% 50V
C877 1-162-282-31 CERAMIC 100PF 10% 50V
< CONNECTOR >
CNP712 1-779-628-11 PIN, CONNECTOR 14P
* CNW711 1-565-384-11 HOLDER, CABLE 3P
< LED >
D101 8-719-071-20 LED L-153HDT (L (LEVEL METER))
D102 8-719-071-20 LED L-153HDT (L (LEVEL METER))
D103 8-719-071-20 LED L-153HDT (L (LEVEL METER))
D104 8-719-071-20 LED L-153HDT (L (LEVEL METER))
D105 8-719-071-20 LED L-153HDT (L (LEVEL METER))
D201 8-719-071-20 LED L-153HDT (R (LEVEL METER))
D202 8-719-071-20 LED L-153HDT (R (LEVEL METER))
D203 8-719-071-20 LED L-153HDT (R (LEVEL METER))
D204 8-719-071-20 LED L-153HDT (R (LEVEL METER))
D205 8-719-071-20 LED L-153HDT (R (LEVEL METER))
D327 8-719-071-21 LED L-113HDT (OPR/BATT)
D328 8-719-071-21 LED L-113HDT (FM STEREO)
< IC >
IC104 8-759-544-73 IC KIA6966S
IC204 8-759-544-73 IC KIA6966S
IC801 8-752-874-88 IC CXP5086H-684Q
< LIQUID CRYSTAL DISPLAY >
LCD801 1-803-156-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R116 1-247-807-31 CARBON 100 5% 1/4W
R117 1-247-807-31 CARBON 100 5% 1/4W
R121 1-249-432-11 CARBON 18K 5% 1/4W
R122 1-249-430-11 CARBON 12K 5% 1/4W
R216 1-247-807-31 CARBON 100 5% 1/4W
R217 1-247-807-31 CARBON 100 5% 1/4W
R221 1-249-432-11 CARBON 18K 5% 1/4W
R222 1-249-430-11 CARBON 12K 5% 1/4W
R367 1-249-420-11 CARBON 1.8K 5% 1/4W
R374 1-247-843-11 CARBON 3.3K 5% 1/4W
R751 1-249-417-11 CARBON 1K 5% 1/4W
R755 1-249-417-11 CARBON 1K 5% 1/4W
R793 1-249-417-11 CARBON 1K 5% 1/4W
R801 1-249-437-11 CARBON 47K 5% 1/4W
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-437-11 CARBON 47K 5% 1/4W
R805 1-249-429-11 CARBON 10K 5% 1/4W
R806 1-249-437-11 CARBON 47K 5% 1/4W
R807 1-249-417-11 CARBON 1K 5% 1/4W
R808 1-249-417-11 CARBON 1K 5% 1/4W
R809 1-249-429-11 CARBON 10K 5% 1/4W
R815 1-249-437-11 CARBON 47K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W
< SWITCH >
S801 1-554-937-11 SWITCH, KEYBOARD (PLAY MODE)
S802 1-554-937-11 SWITCH, KEYBOARD (DISPLAY/ENTER)
S803 1-554-937-11 SWITCH, KEYBOARD (NX)
S804 1-554-937-11 SWITCH, KEYBOARD (x)
S805 1-554-937-11 SWITCH, KEYBOARD (>)
S806 1-554-937-11 SWITCH, KEYBOARD (.)
< VIBRATOR >
X702 1-577-101-11 VIBRATOR, CERAMIC (4.019MHz)
************************************************************
* 1-860-815-11 DC JACK BOARD
**************
1-533-233-21 FUSE HOLDER
< CONNECTOR >
* CNP903 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
* CNP904 1-506-986-11 PIN, CONNECTOR (PC BOARD) 4P
< DIODE >
D905 8-719-046-47 DIODE 1N5401TM
< JACK >
J902 1-507-563-00 JACK, DC (DC IN 12V)
