Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
CFD-CD777SMK2
57
DC JACK FINE TUNING H/P LED MAIN
< FUSE >
0F903 1-533-473-12 FUSE (6.3A/250V)
************************************************************
* 1-670-304-11 FINE TUNING BOARD
*****************
< CONNECTOR >
* CNW1 1-565-384-11 HOLDER, CABLE 3P
< RESISTOR >
R11 1-249-417-11 CARBON 1K 5% 1/4W
< VARIABLE RESISTOR >
RV1 1-225-432-11 RES, VAR, CARBON 100K (FINE TUNING)
************************************************************
* 1-670-299-11 H/P BOARD
**********
< CAPACITOR >
C124 1-126-947-11 ELECT 47uF 20% 35V
C224 1-126-947-11 ELECT 47uF 20% 35V
< CONNECTOR >
CNP306 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< JACK >
J301 1-566-891-11 JACK (PHONES)
< RESISTOR >
R114 1-249-408-11 CARBON 180 5% 1/4W
R214 1-249-408-11 CARBON 180 5% 1/4W
************************************************************
* 1-670-297-11 LED BOARD
**********
3-022-869-01 HOLDER, LED
< CONNECTOR >
CNW307 1-506-987-11 PIN, CONNECTOR (PC BOARD) 5P
< LED >
D329 8-719-071-21 LED L-113HDT (LIVE)
D330 8-719-071-21 LED L-113HDT (PARTY)
D331 8-719-071-21 LED L-113HDT (DISCO)
D332 8-719-071-21 LED L-113HDT (MANUAL)
************************************************************
* A-3321-423-A MAIN BOARD, COMPLETE
*********************
3-008-690-01 KNOB, FUNCTION
3-008-695-01 GEAR, TUNING CAPACITOR
3-008-698-02 KNOB, DUBBING
3-008-718-01 KNOB, DSS
3-026-026-01 KNOB (5P), FUNCTION
3-026-027-01 BRACKET, PWB
7-621-770-87 SCREW +B 2.6X5
7-682-547-04 SCREW +B 3X6
< CAPACITOR >
C1 1-162-306-11 CERAMIC 0.01uF 20% 16V
C2 1-162-286-21 CERAMIC 220PF 10% 50V
C3 1-162-198-31 CERAMIC 8.2PF 10% 50V
C5 1-162-306-11 CERAMIC 0.01uF 20% 16V
C6 1-124-902-00 ELECT 0.47uF 20% 50V
C7 1-126-963-11 ELECT 4.7uF 20% 50V
C8 1-102-942-00 CERAMIC 5PF 0.5PF 50V
C9 1-107-734-11 FILM 360PF 5% 100V
C10 1-164-039-11 CERAMIC 3PF 5% 50V
C11 1-126-960-11 ELECT 1uF 20% 50V
C12 1-136-480-11 FILM 0.0015uF 5% 100V
C13 1-102-942-00 CERAMIC 5PF 0.5PF 50V
C14 1-126-964-11 ELECT 10uF 20% 50V
C15 1-136-287-11 FILM 0.0047uF 5% 100V
C16 1-162-840-11 CERAMIC 0.012uF 10% 16V
C18 1-126-961-11 ELECT 2.2uF 20% 50V
C19 1-162-840-11 CERAMIC 0.012uF 10% 16V
C20 1-162-203-31 CERAMIC 15PF 5% 50V
C21 1-162-306-11 CERAMIC 0.01uF 20% 16V
C22 1-162-192-31 CERAMIC 2.7PF 10% 50V
C23 1-102-959-00 CERAMIC 22PF 5% 50V
C24 1-162-282-31 CERAMIC 100PF 10% 50V
C25 1-104-665-11 ELECT 100uF 20% 25V
C26 1-104-663-11 ELECT 33uF 20% 25V
C27 1-126-947-11 ELECT 47uF 20% 35V
C28 1-126-960-11 ELECT 1uF 20% 50V
C29 1-102-514-11 CERAMIC 22PF 5% 50V
C30 1-126-963-11 ELECT 4.7uF 20% 50V
C31 1-124-902-00 ELECT 0.47uF 20% 50V
C32 1-124-902-00 ELECT 0.47uF 20% 50V
C33 1-162-195-31 CERAMIC 4.7PF 10% 50V
C34 1-162-306-11 CERAMIC 0.01uF 20% 16V
C35 1-162-282-31 CERAMIC 100PF 10% 50V
C36 1-162-306-11 CERAMIC 0.01uF 20% 16V
C37 1-126-961-11 ELECT 2.2uF 20% 50V
C38 1-126-960-11 ELECT 1uF 20% 50V
C41 1-162-282-31 CERAMIC 100PF 10% 50V
C43 1-162-282-31 CERAMIC 100PF 10% 50V
C101 1-162-293-31 CERAMIC 820PF 10% 50V
C102 1-162-291-31 CERAMIC 560PF 10% 50V
C103 1-162-851-11 CERAMIC 0.1uF 10% 16V
C104 1-126-233-11 ELECT 22uF 20% 25V
C105 1-162-294-31 CERAMIC 0.001uF 10% 50V
C106 1-162-291-31 CERAMIC 560PF 10% 50V
C107 1-126-233-11 ELECT 22uF 20% 25V
C108 1-162-840-11 CERAMIC 0.012uF 10% 16V
C109 1-126-960-11 ELECT 1uF 20% 50V
C110 1-126-960-11 ELECT 1uF 20% 50V
C111 1-126-960-11 ELECT 1uF 20% 50V
C112 1-124-902-00 ELECT 0.47uF 20% 50V
C113 1-162-294-31 CERAMIC 0.001uF 10% 50V
C114 1-126-961-11 ELECT 2.2uF 20% 50V
C126 1-162-286-21 CERAMIC 220PF 10% 50V
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
