Sony CFD-CD777SMK2 - Schematic Diagram

2
CFD-CD777SMK2
• PRINTED WIRING BOARD
• SCHEMATIC DIAGRAM
• ELECTRICAL PARTS LIST
MOTOR BOARD
M901
(SPINDLE)
M
S702
(LIMIT)
M902
(SLED)
M
6
CN703
1
1-680-758-
41
TO
MAIN
BOARD
CNP703
M902
M901
S702
CN703
TO
MAIN
BOARD
CNP703
6P
(SPINDLE)
(SLED)
(LIMIT)
SP+
SP-
SL+
SL-
LIMIT
GND
Ref. No. Part No. Description Remark
MOTOR BOARD
*************
< CONNECTOR >
CN703 1-817-612-11 PIN, CONNECTOR (SMALL TYPE) 6P
< SWITCH >
S702 1-572-085-21 SWITCH, LEAF (LIMIT)
************************************************************
MISCELLANEOUS
**************
0801 8-848-483-12 OPTICAL PICK-UP (KSS-213C/C2RP1)
805 X-2626-202-1 CHASSIS ASSY (MB) (RP), MOTOR
(including M901 (SPINDLE))
M902 X-2625-769-1 GEAR ASSY (MB) (RP), MOTOR (SLED)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
