D BOARD IC VOLTAGE LIST
IC401 IC620 IC654 IC901
pin volt pin volt pin volt pin volt
1 0.7 1 1.5 I 15.0 1 12.0
2 15.0 2 2.0 G GND 2 12.0
3 -13.4 3 2.1 O 12.0 3 8.7
4 -15.0 4 2.3
IC680 4 GND
5 0.6 5 GND pin volt 5 8.6
6 14.3 6 -0.1 1 2.0 6 8.6
7 0.7 7 4.4 2 GND 7 NC
IC501 8 15.1 3 4.9 8 GND
pin volt 9 0.0
IC701 9NC
1 15 10 10.2 pin volt 10 3.8
2 15 11 GND 1 1.5 11 0.0
3 10.1 12 4.4 2 1.5 12 8.9
4 GND 13 NC 3 1.5 13 0.0
5 8 14 200.0 4 1.5 14 5.4
6 4.7 15 190.3 5 -15.0 15 GND
7 4.7 16 194.7 6 1.5 16 NC
8 GND 17 NC 7 1.5 17 2.5
9 3 18 NC 8 0.2 18 2.6
10 3.8
IC630 9 0.2 19 NC
11 3.2 pin volt 10 15.0 20 9.1
12 3.2 1 0.0
IC702 IC902
13 GND 2 0.0 pin volt pin volt
14 0.5 3 -0.1 1 0.0 1 -0.1
15 GND 4 20.0 2 0.8 2 -0.1
16 3.7 5 GND 3 0.8 3 GND
17 2.6 6 1.4 4 0.8 4 GND
18 9 7 16.1 5 0.8 5 3.8
IC610 8 4.8 6 -0.1 6 3.8
pin volt
IC640 7 -15.0 7 8.6
1 90.7 pin volt 8 GND 8 15.0
2 NC 1 7.1 9 15.0 All voltages are in V
3 90.4 2 12.8 10 4.8
4 0 3 GND
IC703
5 2.2 IC652 pin volt
6 NC pin volt 1 1.2
7 GND 1 3.3 2 1.2
8 2.2 2 7.0 3 -15.0
9 14.6 3 GND 4 0.2
10 378 4 5.0 5 15.0
5 6.7
D BOARD TRANSISTOR LIST
BCE GDS
Q501 0.3 6.1 GND Q504 -10.4 -0.2 -15
Q502 6.1 12 6.1 Q506 200 66.6 217.4
Q503 6.1 GND 6.1 Q511 0.2 26.5 GND
Q505 -1.3 66.7 GND Q512 4.9 24.8 GND
Q507 -0.7 12 0.2 Q513 0.2 24.8 GND
Q508 10.1 15 9.8 Q514 0.2 24.8 GND
Q509 10.1 GND 9.8 Q515 0.2 24.8 GND
Q510 0.9 12.8 0.4 Q516 0.2 24.8 GND
Q519 1.2 9 GND Q517 0.2 24.8 GND
Q521 0.2 5.6 GND Q630 1.2 385 1.2
Q524 0.2 5.6 GND Q640 4.4 190.1 GND
Q610 1.8 16.6 16.6 Q641 194.6 378 190.1
Q611 0 12.1 GND Q901 218.5 54.4 200
Q652 4.1 0 GND Q902 8.2 54.8 GND
Q701 1.2 32.1 0
All voltages are in V
Q702 33.8 80 33.4
Q703 32.1 GND 32.9
Q704 33.4 80 33.3
Q705 32.9 GND 33.1
Q706 1.8 107.8 1.3
Q707 1.2 GND 1.8
Q905 9.4 72.5 8.8
Q906 3.6 GND 8.8
Q907 3.7 GND 0.7
All voltages are in V
