Sony CX-BK1 - Page 71

71
CX-BK1
– CONNECTOR Board –
IC701, 711, 721 BA6956AN
1 2 3 4 5 6 7 8 9
CONTROL LOGIC
TSD
VREF
O
UT2
O
UT1
RNF
VM
VCC
FIN
GND
RIN
– MAIN Board –
IC501 BU4052BCF-E2
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
2X0
X2
VDD
X1
XCOM
X0
X3
A
B
VSS
VEE
INH
2X1
2X3
2XCOM
2X2
IC601 M61529FP-D60G
1
REF
2
MIC
3
INA1
REF
EXTERNAL
INPUT ATT
INPUT
ATT
4
INB1
5
INC1
6
IND1
7
RECA1/INEX1
8
RECB1
9
TMI1
10
TMO1
11
TCA1
12
TCB1
13
TCC1
14
TOUT1
16
BB A1
17
BB B1
15
VOLIN1
VOCAL
CUT
TONE ATT
+
TONE CONTROL
(BASS/MID/TREBLE)
ELECTRICAL
VOLUME
18
OUT1
19
SAOUT
20
VCC
BASS
BOOST
21
DATA
MCU
INTERFACE
42
SUR1/DPL1
41
SUR2/DPL2
40
INA2
INPUT
ATT
39
INB2
38
INC2
37
IND2
36
RECA1/INEX2
35
RECB2
34
TMI2
33
TMO2
32
TCA2
31
TCB2
30
TCC2
29
TOUT2
27
BB A2
26
BB B2
28
VOLIN2
+
TONE ATT
TONE CONTROL
(BASS/MID/TREBLE)
ELECTRICAL
VOLUME
25
OUT2
24
SWOUT
23
GND
BASS
BOOST
22
CLOCK
+
SURROUND
OR
DPL BUFFER
+
