Sony CX-BK1 - Optical Pick-Up Section (BU-30 CBD64 NS)

92
CX-BK1
9-14. OPTICAL PICK-UP SECTION
(BU-30CBD64NS)
808
802
807
801
803
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
801 4-236-304-02 SPRING (SLED), LEAF
802 A-4731-674-A BD BOARD, COMPLETE
803 3-372-761-01 SCREW (M1.7), TAPING
0807 A-4735-189-A BU-30 (61) ASSY
808 1-782-817-11 WIRE (FLAT TYPE)(16 CORE)
The components identified by mark 0 or dotted
line with mark 0 are critical for safety.
Replace only with part number specified.
