77
CX-BK1
Pin No. Pin Name I/O Description
90 ELV_E0 I ELV_E0 switch signal input from the CD mechanism
91 RE_TRE I
Jog dial pulse input from the rotary encoder (TREBLE/MIDDLE)
92 RE_BAS I
Jog dial pulse input from the rotary encoder (BASS)
93 RE_VOL I
Jog dial pulse input from the rotary encoder (VOLUME)
94 RE_JOG I
Jog dial pulse input from the rotary encoder (MULTIJOG)
95 KEY3 I
Key input terminal (A/D input)
96 KEY2 I
Key input terminal (A/D input)
97 KEY1 I
Key input terminal (A/D input)
98 POWER_MONI I Voltage detection signal input terminal
99 LEVEL I Level mater signal input terminal
100 SUFIX I Destination setting input terminal
