CX-JTD8
Pin No. Pin Name I/O Description
117 RFIN I RF signal input from the CD/DVD RF amplifier
118, 119
VCCA5, VCCA4 — Power supply (+3.3V)
120 VCOR1 — VCO oscillating range setting resistor connected
121 VCOIN I VCO input
122, 123
GNDA4, GNDA3 — Ground
124 LPF5 O Signal output from the operation amplifier from PLL loop filter
125 VC1 I Middle point voltage (+1.65V) input
126, 127 LPF2, LPF1 I Inverted signal input to the operation amplifier from PLL loop filter
128, 129
VCCA3, VCCA2 — Power supply (+3.3V)
130 PDO O Signal output from the charge pump for phase comparator
131 PDHVCC I Middle point voltage input terminal for RF PLL
132 FDO O Signal output from the charge pump for frequency comparator
133, 134
GNDA2, GNDA1 — Ground
135 SPO O Spindle motor control signal output to FAN8035L
136 VC2 I Middle point voltage (+1.65V) input
137 MDIN2 I Spindle motor servo drive signal input
138 MDIN1 I MDP input
139 VCCA1 — Power supply (+3.3V)
140 CLVS O Control signal output for selection the spindle control filter constant at CLVS
141 VSS — Ground
142 MDSOUT O Frequency error output terminal of internal CLV circuit
143 VDD — Power supply (+3.3V)
144 MDPOUT O Phase error output of internal CLV circuit
145 DEFECT I Defect signal input (Not used)
146 GSCOR I Guard subcode sync (S0+S1) detection signal input from CXD3068Q
147 EXCK O Subcode serial data reading clock signal output to CXD3068Q
148 SBIN I Subcode serial data input from CXD3068Q
149 VSS — Ground
150 SCOR I Subcode sync (S0+S1) detection signal input from CXD3068Q
151 WFCK I Write frame clock signal input from CXD3068Q
152 VDD5V — Power supply (+5V)
153 XRCI I Not used (Pull down)
154 VDDS — Power supply (+5V)
155 C2PO I C2 pointer signal input from CXD3068Q
156 VDD — Power supply (+3.3V)
157 DBCK O Bit clock signal (2.8224 MHz) output (Not used)
158 BCLK I Bit clock signal (2.8224 MHz) input from CXD3068Q
159 DDAT O PCM data (Not used)
160 MDAT I Serial data input from CXD3068Q
161 VSS — Ground
162 DLRC O L/R sampling clock signal (Not used)
163 LRCK I L/R sampling clock signal (44.1 kHz) input from CXD3068Q
164 XRST I Reset signal input from CXP973064-226R “L”: reset
165 IFS0 I Not used (connected to ground)
166 IFS1 I Not used (connected to VDD)
167 XTAL I 33.8688 MHz clock signal input from SM8707GV
