– 36 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
D210 8-719-072-96 LED TLO124(TPJ52) (HL)
D211 8-719-072-96 LED TLO124(TPJ52) (HR)
D212 8-719-072-96 LED TLO124(TPJ52) (LS)
D213 8-719-072-96 LED TLO124(TPJ52) (RS)
D214 8-719-812-41 LED TLR124 (DOLBY VIRTUAL)
D216 8-719-812-41 LED TLR124 (MUSIC)
D301 8-719-992-13 LED LIR5BE
D302 8-719-992-13 LED LIR5BE
D303 8-719-992-13 LED LIR5BE
D304 8-719-992-13 LED LIR5BE
D305 8-719-992-13 LED LIR5BE
D306 8-719-992-13 LED LIR5BE
D307 8-719-992-13 LED LIR5BE
D308 8-719-992-13 LED LIR5BE
< IC >
IC205 8-759-560-82 IC uPD6345GS-T1
IC206 8-759-560-82 IC uPD6345GS-T1
< JUMPER RESISTOR >
JC202 1-216-296-00 SHORT 0
JC204 1-216-296-00 SHORT 0
JC301 1-216-296-00 SHORT 0
< TRANSISTOR >
Q301 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q302 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q351 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q352 8-729-106-68 TRANSISTOR 2SD1615A-GP
< RESISTOR >
R201 1-216-033-00 METAL CHIP 220 5% 1/10W
R202 1-216-033-00 METAL CHIP 220 5% 1/10W
R203 1-216-033-00 METAL CHIP 220 5% 1/10W
R204 1-216-033-00 METAL CHIP 220 5% 1/10W
R205 1-216-033-00 METAL CHIP 220 5% 1/10W
R206 1-216-033-00 METAL CHIP 220 5% 1/10W
R207 1-216-041-00 METAL CHIP 470 5% 1/10W
R208 1-216-041-00 METAL CHIP 470 5% 1/10W
R209 1-216-041-00 METAL CHIP 470 5% 1/10W
R210 1-216-041-00 METAL CHIP 470 5% 1/10W
R211 1-216-041-00 METAL CHIP 470 5% 1/10W
R212 1-216-041-00 METAL CHIP 470 5% 1/10W
R213 1-216-041-00 METAL CHIP 470 5% 1/10W
R214 1-216-033-00 METAL CHIP 220 5% 1/10W
R216 1-216-033-00 METAL CHIP 220 5% 1/10W
R301 1-216-003-11 RES,CHIP 12 5% 1/10W
R302 1-216-003-11 RES,CHIP 12 5% 1/10W
R351 1-216-003-11 RES,CHIP 12 5% 1/10W
R352 1-216-003-11 RES,CHIP 12 5% 1/10W
< SWITCH >
SW1 1-572-199-11 SWITCH, KEY BOARD (POWER)
SW2 1-572-199-11 SWITCH, KEY BOARD (INPUT)
SW3 1-572-199-11 SWITCH, KEY BOARD (OUTPUT)
SW4 1-572-199-11 SWITCH, KEY BOARD (EFFECT)
SW5 1-572-199-11 SWITCH, KEY BOARD (DEMO)
*************************************************************
* A-4542-553-A TX BOARD, COMPLETE
*******************
7-685-146-11 SCREW +P 3X8 TYPE2 NON-SLIT
< CAPACITOR >
C1 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C2 1-136-161-00 FILM 0.047uF 5% 50V
C3 1-124-589-11 ELECT 47uF 20% 16V
C5 1-124-234-00 ELECT 22uF 20% 16V
C6 1-124-589-11 ELECT 47uF 20% 16V
C7 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C8 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C9 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C10 1-163-107-00 CERAMIC CHIP 39PF 5% 50V
C11 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C12 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C13 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C14 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C30 1-124-589-11 ELECT 47uF 20% 16V
C31 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C32 1-124-233-11 ELECT 10uF 20% 16V
C33 1-124-589-11 ELECT 47uF 20% 16V
C34 1-124-589-11 ELECT 47uF 20% 16V
C36 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C37 1-124-589-11 ELECT 47uF 20% 16V
C38 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C39 1-124-589-11 ELECT 47uF 20% 16V
C40 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C51 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C52 1-136-161-00 FILM 0.047uF 5% 50V
C55 1-124-234-00 ELECT 22uF 20% 16V
C56 1-124-589-11 ELECT 47uF 20% 16V
C57 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C58 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C59 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C60 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C61 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
C62 1-163-111-00 CERAMIC CHIP 56PF 5% 50V
C63 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C64 1-163-006-11 CERAMIC CHIP 560PF 10% 50V
C71 1-126-160-11 ELECT 1uF 20% 50V
C101 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C102 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C103 1-124-233-11 ELECT 10uF 20% 16V
C104 1-124-233-11 ELECT 10uF 20% 16V
C105 1-124-257-00 ELECT 2.2uF 20% 50V
C106 1-124-257-00 ELECT 2.2uF 20% 50V
TXLED
