– 6 –
2-3. PANEL ASSY, SUB
2-4. TX BOARD
3
LED board
4
panel assy, su
b
1
P 2.6X6
2
P 2.6X6
4
TX board
2
PTT 2.6X5
1
P 3X6
3
PTT 2.6X5
