– 35 –
SECTION 7
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
AMP
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
When indicating parts by reference
number, please include the board.
* A-4542-552-A AMP BOARD, COMPLETE
*********************
< CAPACITOR >
C901 1-115-197-11 ELECT 100uF 20% 25V
C902 1-115-197-11 ELECT 100uF 20% 25V
C903 1-127-694-11 ELECT 47uF 20% 25V
C904 1-127-694-11 ELECT 47uF 20% 25V
C907 1-127-693-11 ELECT 1000uF 20% 16V
C908 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C909 1-115-198-11 ELECT 470uF 20% 25V
C910 1-115-198-11 ELECT 470uF 20% 25V
C915 1-124-589-11 ELECT 47uF 20% 16V
C917 1-104-541-11 FILM CHIP 0.0015uF 5% 50V
C918 1-104-541-11 FILM CHIP 0.0015uF 5% 50V
< IC >
IC901 8-759-545-66 IC NJM3414AM-TE2
< JACK >
J901 1-766-850-11 JACK (LARGE TYPE) (PHONES)
< COIL >
L901 1-412-963-11 INDUCTOR 100uH
< TRANSISTOR >
Q901 8-729-043-69 TRANSISTOR UN2225-(TX).SO
Q902 8-729-043-69 TRANSISTOR UN2225-(TX).SO
< RESISTOR >
R901 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R902 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R903 1-216-081-00 METAL CHIP 22K 5% 1/10W
R904 1-216-081-00 METAL CHIP 22K 5% 1/10W
R905 1-216-083-00 METAL CHIP 27K 5% 1/10W
R906 1-216-083-00 METAL CHIP 27K 5% 1/10W
R907 1-216-049-11 RES,CHIP 1K 5% 1/10W
R908 1-216-049-11 RES,CHIP 1K 5% 1/10W
R909 1-216-083-00 METAL CHIP 27K 5% 1/10W
R910 1-216-083-00 METAL CHIP 27K 5% 1/10W
R911 1-216-015-00 METAL CHIP 39 5% 1/10W
R912 1-216-015-00 METAL CHIP 39 5% 1/10W
R913 1-216-025-00 RES,CHIP 100 5% 1/10W
R914 1-216-025-00 RES,CHIP 100 5% 1/10W
R917 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R920 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R921 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R922 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
< VARIABLE RESISTOR >
RV901 1-237-671-11 RES, VAR, CARBON 10K/10K (PHONES LEVEL)
*************************************************************
* A-4542-551-A LED BOARD, COMPLETE
********************
4-213-951-01 SPRING, GROUND
< CAPACITOR >
C201 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C202 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C203 1-124-589-11 ELECT 47uF 20% 16V
C204 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C205 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C206 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C207 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C208 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C209 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C210 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C211 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C212 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C213 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C301 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C351 1-126-382-11 ELECT 100uF 20% 16V
< CONNECTOR >
CN902 1-691-071-31 HOUSING, CONNECTOR 12P
CN903 1-691-065-31 HOUSING, CONNECTOR 6P
< DIODE >
D201 8-719-072-97 LED TLG124A(TPJ52) (POWER)
D202 8-719-812-41 LED TLR124 (DIGITAL)
D203 8-719-812-41 LED TLR124 (ANALOG)
D204 8-719-812-41 LED TLR124 (VIRTUAL)
D205 8-719-812-41 LED TLR124 (DOLBY SURROUND)
D206 8-719-812-41 LED TLR124 (DOLBY DIGITAL)
D207 8-719-072-96 LED TLO124(TPJ52) (L)
D208 8-719-072-96 LED TLO124(TPJ52) (C)
D209 8-719-072-96 LED TLO124(TPJ52) (R)
LED
