– 38 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
IC202 8-759-530-30 IC TC74VHCU04FT(EL)
IC204 8-759-526-81 IC RN5VL42AA-TL
IC301 8-759-560-81 IC ZR38600PQC-RCB7A
IC302 8-759-565-85 IC DSP56009FJ88E
IC303 8-759-491-47 IC TC74VHCT08AFT(EL)
IC304 8-759-491-47 IC TC74VHCT08AFT(EL)
IC305 8-759-242-84 IC TORX176 (DIGITAL IN)
IC801 8-759-094-53 IC TA7805S
IC802 8-759-471-81 IC PQ05RD11
IC803 8-759-445-59 IC BA033T
IC804 8-759-459-99 IC PQ09RD11
IC805 8-759-459-99 IC PQ09RD11
< JACK >
J101 1-784-653-11 JACK, PHONO 2P (LINE INPUT)
J801 1-785-066-11 JACK, DC (POLARITY UNIFIED TYPE)
(DC IN 9V)
< JUMPER RESISTOR >
JC122 1-216-295-00 SHORT 0
JC123 1-216-295-00 SHORT 0
JC125 1-216-295-00 SHORT 0
JC232 1-216-295-00 SHORT 0
JC233 1-216-295-00 SHORT 0
JC234 1-216-295-00 SHORT 0
JC235 1-216-295-00 SHORT 0
JC236 1-216-295-00 SHORT 0
JC237 1-216-295-00 SHORT 0
JC238 1-216-295-00 SHORT 0
JC239 1-216-295-00 SHORT 0
JC240 1-216-295-00 SHORT 0
JC243 1-216-295-00 SHORT 0
JC301 1-216-295-00 SHORT 0
JC309 1-216-295-00 SHORT 0
JC316 1-216-295-00 SHORT 0
JC317 1-216-295-00 SHORT 0
JC318 1-216-295-00 SHORT 0
JC319 1-216-295-00 SHORT 0
JC320 1-216-295-00 SHORT 0
JC321 1-216-295-00 SHORT 0
JC322 1-216-295-00 SHORT 0
JC323 1-216-295-00 SHORT 0
JC324 1-216-295-00 SHORT 0
JC325 1-216-295-00 SHORT 0
JC326 1-216-295-00 SHORT 0
JC328 1-216-295-00 SHORT 0
JC329 1-216-295-00 SHORT 0
JC330 1-216-295-00 SHORT 0
JC331 1-216-295-00 SHORT 0
JC332 1-216-295-00 SHORT 0
< COIL >
L1 1-409-693-11 COIL (OSC)
L2 1-412-961-11 INDUCTOR 68uH
L51 1-409-692-11 COIL (OSC)
L52 1-412-962-11 INDUCTOR 82uH
L101 1-416-668-11 INDUCTOR 10uH
L102 1-416-668-11 INDUCTOR 10uH
L201 1-416-668-11 INDUCTOR 10uH
L301 1-416-668-11 INDUCTOR 10uH
L302 1-416-668-11 INDUCTOR 10uH
L303 1-416-668-11 INDUCTOR 10uH
L801 1-411-197-11 COIL, DD CONVERTER
L802 1-416-668-11 INDUCTOR 10uH
L803 1-469-349-11 INDUCTOR 1uH
< FILTER >
LF101 1-411-236-11 FILTER, EMI
LF801 1-416-846-21 COIL, LINE FILTER
< TRANSISTOR >
Q1 8-729-200-87 TRANSISTOR 2SC2714-Y
Q2 8-729-216-22 TRANSISTOR 2SA1162-G
Q31 8-729-043-69 TRANSISTOR UN2225-(TX).SO
Q32 8-729-043-69 TRANSISTOR UN2225-(TX).SO
Q33 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q34 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q35 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q36 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q51 8-729-200-87 TRANSISTOR 2SC2714-Y
Q52 8-729-216-22 TRANSISTOR 2SA1162-G
Q101 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q102 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q803 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R2 1-216-073-00 METAL CHIP 10K 5% 1/10W
R3 1-216-089-00 RES,CHIP 47K 5% 1/10W
R4 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R5 1-216-025-00 RES,CHIP 100 5% 1/10W
R6 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R7 1-216-073-00 METAL CHIP 10K 5% 1/10W
R8 1-216-063-00 RES,CHIP 3.9K 5% 1/10W
R9 1-216-063-00 RES,CHIP 3.9K 5% 1/10W
R10 1-216-081-00 METAL CHIP 22K 5% 1/10W
R11 1-216-107-00 METAL CHIP 270K 5% 1/10W
R12 1-216-025-00 RES,CHIP 100 5% 1/10W
R13 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R14 1-216-747-11 METAL CHIP 33K 1% 1/10W
R15 1-216-596-11 RES,CHIP 2.7K 1% 1/10W
R16 1-216-047-00 RES,CHIP 820 5% 1/10W
R17 1-216-075-00 METAL CHIP 12K 5% 1/10W
R30 1-216-049-11 RES,CHIP 1K 5% 1/10W
R32 1-216-133-00 METAL CHIP 3.3M 5% 1/10W
R33 1-216-049-11 RES,CHIP 1K 5% 1/10W
R52 1-216-073-00 METAL CHIP 10K 5% 1/10W
