Sony DSLR-A200 Instruction Manual (DSLR-A200) User Manual

28
Note
• The eyepiece sensors located below the viewfinder may be activated depending on
the situation, and the focus may be adjusted or the LCD monitor may continue to
flash. In such cases, set [Eye-Start AF] (page 69) and [Auto off w/ VF] (page 115) to
[Off].
1 Carefully slide the eyecup off by
pushing on each side of the
eyecup.
2 Slide the eyepiece cover over the
viewfinder.

Sony DSLR-A200 Instruction Manual (DSLR-A200) Specifications

General

Model	DSLR-A200
Effective Pixels	10.2 megapixels
Sensor Type	CCD
Sensor Size	23.6 x 15.8 mm
Autofocus Points	9 points
Continuous Shooting Speed	3 fps
LCD Screen Size	2.7 inches
LCD Screen Resolution	230, 400 dots
Viewfinder Coverage	95%
Storage Media	CompactFlash Type I/II, Microdrive
Type	Digital SLR camera
ISO Sensitivity	ISO 100-3200
Shutter Speed	1/4000 to 30 sec
Viewfinder Type	Optical
Lens Mount	Sony A-mount
Battery	NP-FM500H
Weight	532 g (body only)
Dimensions	130.8 x 98.5 x 71.3 mm
