• When Single bracket is selected, if the shutter button is pressed halfway
down and released, “br 1” appears for the ambient light bracket and “Fbr
1” appears for the flash bracket in the viewfinder. When bracket shooting
starts, it indicates what number the next frame is, for instance, “br 2,” “br
3.”
* Ambient light: Any light other than the flash light that shines on the scene
for an extended period of time, such as natural light, a light bulb, or a
fluorescent light.
Based on the selected white balance, and color temperature/color filter,
three images are taken.
*1
The value beneath is the value currently selected.
*2
Mired: a unit to indicate the color conversion quality in color temperature filters.
Shooting with white balance shifted (WB bracket)
1 button t (WB bracket) t Select the desired
setting
2 Adjust the focus and shoot the subject.
*
1
(WB
bracket)
Shoots three images with the white balance shifted. When Lo
is selected, it is shifted by 10 mired*
2
, and when Hi is
selected, it is shifted by 20 mired. One shot records three
images.

Sony DSLR-A200 Instruction Manual (DSLR-A200) Specifications

General

Model	DSLR-A200
Effective Pixels	10.2 megapixels
Sensor Type	CCD
Sensor Size	23.6 x 15.8 mm
Autofocus Points	9 points
Continuous Shooting Speed	3 fps
LCD Screen Size	2.7 inches
LCD Screen Resolution	230, 400 dots
Viewfinder Coverage	95%
Storage Media	CompactFlash Type I/II, Microdrive
Type	Digital SLR camera
ISO Sensitivity	ISO 100-3200
Shutter Speed	1/4000 to 30 sec
Viewfinder Type	Optical
Lens Mount	Sony A-mount
Battery	NP-FM500H
Weight	532 g (body only)
Dimensions	130.8 x 98.5 x 71.3 mm
