Sony DSLR-A200 Instruction Manual (DSLR-A200) User Manual

41
Before your operation
Selecting a function/setting
You can select a function for shooting or playback from the menu list. To
display the menu list, press the Fn (Function) button, (Drive)
button, or MENU button.
In this instruction manual, the process of selecting a function with the
controller from the menu list is described as follows:
Example: Fn button t [White balance] t Select the desired
setting
When you start the operation, an operation guide of controller functions
will be displayed at the bottom of the screen. Please refer to the guide when
operating the camera. The step-by-step description of the above example is
as follows:
Example: When the Fn button is pressed.
From the menu list, use the controller to
move the cursor to the setting of your
choice and execute the selection.
: Press v/V/b/B on the controller to
move the cursor.
z: Press the center button to execute the
selection.
1 Press the Fn button.

Sony DSLR-A200 Instruction Manual (DSLR-A200) Specifications

General

Model	DSLR-A200
Effective Pixels	10.2 megapixels
Sensor Type	CCD
Sensor Size	23.6 x 15.8 mm
Autofocus Points	9 points
Continuous Shooting Speed	3 fps
LCD Screen Size	2.7 inches
LCD Screen Resolution	230, 400 dots
Viewfinder Coverage	95%
Storage Media	CompactFlash Type I/II, Microdrive
Type	Digital SLR camera
ISO Sensitivity	ISO 100-3200
Shutter Speed	1/4000 to 30 sec
Viewfinder Type	Optical
Lens Mount	Sony A-mount
Battery	NP-FM500H
Weight	532 g (body only)
Dimensions	130.8 x 98.5 x 71.3 mm
