Sony DVP-S7700 - Page 64

DVP-S7700
4-59 4-60
EURO AV
ER-8
POWER BLOCK
(HS-930SH)
(SWITCHING REGULATOR)
MB-84
(SIGNAL PROCESS/
SERVO)
HP-120
(HEAD PHONE)
PW-120
(IR/POWER SWITCH)
FR-160
(FUNCTION SWITCH)
DC MOTOR
(SPINDLE)
DR-88
(DOOR SENSOR)
CN-113
(DOOR MOTOR)
TK-47
(RF/SERVO)
YS-19
(COMPONENT
VIDEO)
AU-218
(AUDIO)
FG-43
(SLED)
PS-421
(AUDIO POWER)
FP-75
(FL DRIVER)
FL-108
(FUNCTION SWITCH)
ER-8 (AEP, UK)
(EURO AV)
ER-8 BOARD (SIDE A)
D601 B-4
D607 A-5
D608 A-5
D609 A-6
D610 A-6
D616 A-2
D617 A-3
D618 A-3
D619 A-3
D620 A-4
D622 A-2
D623 A-2
D625 C-4
D626 C-2
D627 C-5
D628 B-2
D633 C-3
D634 C-3
IC603 B-2
IC604 B-4
IC607 B-3
IC608 B-5
Q601 C-4
Q602 C-6
Q604 B-4
Q605 B-4
Q607 A-4
Q608 B-4
Q612 C-5
Q614 A-5
Q615 B-5
Q622 B-5
Q623 B-5
Q625 A-5
Q626 B-5
Q633 A-6
Q634 B-6
Q635 C-5
Q636 A-4
Q637 C-5
Q638 C-4
Q639 C-4
Q643 C-3
Q644 C-3
ER-8 (EURO AV) PRINTED WIRING BOARD
– Ref. No.: ER-8 board; 1,000 series –
– AEP, UK –
There are few cases that the part isn't mounted in this model is printed on this diagram.
1-671-916-
05
(11)
11
ER-8 BOARD(SIDE A)
A
B
C
D
1
2
3 4
5 6
