Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D651 8-719-988-61 DIODE 1SS355TE-17
D681 8-719-988-61 DIODE 1SS355TE-17 (AEP,G,UK,CIS)
D801 8-719-988-61 DIODE 1SS355TE-17
D822 8-719-988-61 DIODE 1SS355TE-17
D841 8-719-988-61 DIODE 1SS355TE-17
D861 8-719-988-61 DIODE 1SS355TE-17
D891 8-719-988-61 DIODE 1SS355TE-17 (US,CND,DX7,DX7J)
D892 8-719-988-61 DIODE 1SS355TE-17 (US,CND,DX7,DX7J)
D901 8-719-200-82 DIODE 11ES2-TB5
D902 8-719-200-82 DIODE 11ES2-TB5
D903 8-719-200-82 DIODE 11ES2-TB5
D904 8-719-200-82 DIODE 11ES2-TB5
D906 8-719-200-82 DIODE 11ES2-TB5
D907 8-719-200-82 DIODE 11ES2-TB5
D908 8-719-200-82 DIODE 11ES2-TB5
D909 8-719-200-82 DIODE 11ES2-TB5
D910 8-719-200-82 DIODE 11ES2-TB5
D911 8-719-200-82 DIODE 11ES2-TB5
D952 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB201 1-216-295-91 SHORT 0
FB202 1-216-295-91 SHORT 0
FB203 1-216-295-91 SHORT 0
FB204 1-216-295-91 SHORT 0
FB416 1-216-295-91 SHORT 0
FB462 1-216-295-91 SHORT 0
FB499 1-216-295-91 SHORT 0
< FRONT END >
FE601 1-693-477-11 FRONT END (3 GANGS) (DX7,DX7J)
FE602 1-693-478-11 FRONT END (FM3 GANGS) (US,CND)
FE603 1-693-496-11 FRONT END (4 GANGS) (AEP,G,UK,CIS)
< IC >
IC101 8-759-652-04 IC M61504FP-TP
IC102 8-759-099-06 IC M5218AFP-TE1
IC104 8-759-099-06 IC M5218AFP-TE1 (DX7,DX7J)
IC201 8-749-923-04 IC TOTX178A (OPTICAL DIGITAL OUT)
IC301 8-759-652-80 IC HA12227F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-TE
IC304 8-759-656-83 IC NJM4580MD-TE
IC401 8-759-652-48 IC M30622MAA-A25FP
IC501 8-759-635-63 IC M51943BSL-TP
IC601 8-759-652-00 IC BA1450
IC651 8-759-288-54 IC LC72130
IC681 8-759-099-06 IC M5218AFP-TE1 (AEP,G,UK,CIS)
IC682 8-759-541-48 IC BU1924 (AEP,G,UK,CIS)
IC911 8-759-039-69 IC uPC7805AHF
IC921 8-759-088-08 IC uPC7812AHF
IC931 8-759-604-86 IC M5F7807L
IC951 8-759-158-62 IC TA78057S
IC961 8-759-701-59 IC M5F7809L
< IFT >
IFT601 1-435-295-11 TRANSFORMER, IF
< JACK >
J101 1-793-987-11 JACK, PIN 2P (MD/VIDEO)
J102 1-774-819-11 JACK, PIN 2P (SURROUND SPEAKER)
< JUMPER RESISTOR >
JR1 1-216-296-91 SHORT 0
JR2 1-216-296-91 SHORT 0
JR3 1-216-296-91 SHORT 0
JR4 1-216-296-91 SHORT 0
JR6 1-216-296-91 SHORT 0
JR7 1-216-296-91 SHORT 0
JR8 1-216-295-91 SHORT 0
JR9 1-216-295-91 SHORT 0
JR13 1-216-296-91 SHORT 0
JR14 1-216-296-91 SHORT 0
JR15 1-216-296-91 SHORT 0
JR17 1-216-296-91 SHORT 0
JR18 1-216-295-91 SHORT 0
JR19 1-216-296-91 SHORT 0
JR23 1-216-296-91 SHORT 0
JR24 1-216-296-91 SHORT 0
JR25 1-216-296-91 SHORT 0
JR26 1-216-296-91 SHORT 0
JR27 1-216-296-91 SHORT 0
JR29 1-216-296-91 SHORT 0
JR31 1-216-295-91 SHORT 0
JR32 1-216-296-91 SHORT 0
JR33 1-216-296-91 SHORT 0
JR34 1-216-295-91 SHORT 0
JR35 1-216-296-91 SHORT 0
JR36 1-216-295-91 SHORT 0
JR37 1-216-296-91 SHORT 0
JR38 1-216-296-91 SHORT 0
JR39 1-216-296-91 SHORT 0
JR42 1-216-295-91 SHORT 0
JR44 1-216-296-91 SHORT 0
JR45 1-216-296-91 SHORT 0
JR50 1-216-296-91 SHORT 0 (BX7)
JR51 1-216-296-91 SHORT 0
JR52 1-216-296-91 SHORT 0
JR53 1-216-296-91 SHORT 0
JR54 1-216-295-91 SHORT 0 (DX7J)
JR54 1-216-296-91 SHORT 0 (EXCEPT TH,DX7J)
JR140 1-216-296-91 SHORT 0
JR601 1-216-296-91 SHORT 0 (EXCEPT US,CND)
JR602 1-216-295-91 SHORT 0
JR603 1-216-296-91 SHORT 0
JR604 1-216-296-91 SHORT 0
JR605 1-216-296-91 SHORT 0
JR606 1-216-296-91 SHORT 0
JR607 1-216-295-91 SHORT 0
JR608 1-216-296-91 SHORT 0
JR609 1-216-295-91 SHORT 0
JR611 1-216-296-91 SHORT 0
JR612 1-216-296-91 SHORT 0 (US,CND)
JR614 1-216-296-91 SHORT 0 (AEP,G,UK,CIS)
JR615 1-216-295-91 SHORT 0
JR616 1-216-295-91 SHORT 0
JR619 1-216-295-91 SHORT 0
JR632 1-216-295-91 SHORT 0 (US,CND)
MAIN
