Sony HCD-BX7 - Page 9

9
q; Cut the eleven melted-connection points with a cutting plier.
Note: When attching the panel board,
refer to "Service Note" on page 4.
qs Panel board
9 CD Switch boar
d
VCD Switch board
1 Knob (Volume)
6
5
FR knob
4 Bracket (FR)
qa Five claws
8 Three claws
7 Two screws
(+BVTP 2.6
× 8)
3 Two bosses & four pins
2 Two screws
(+BVTP 2.6
× 8)
qs Two screws
(+BVTT 4
× 8)
3 Two screws
(+BVTP 3
× 8)
6 Six screws
(+BVTP 3
× 10
)
5 Two screws
(+BVTP 3
× 10)
8 Panel, back
qa Two screws (+BVTT 4 × 8)
qf Trans board
4 Sub-trans
board
qd Trans
1 Connector (CN975)
9 Connector (CN975)
0 Connector (CN977)
7 Connector (CN891)
2 Connector (CN974)
3-5. PANEL BOARD
3-6. SUB-TRANS BOARD AND TRANS BOARD
