SECTION 2
GENERAL
1 DISC SKIP EX-CHANGE button
2 DISC 1 button and indicator
3 DISC 2 button and indicator
4 DISC 3 button and indicator
5 Z OPEN/CLOSE button
6 EDIT, TUNER MOMERY button
7 PLAY MODE, STEREO/MONO button
8 REPEAT, DOLBY NR button
9 DIRECTION knob (DX9 model)
DIRECTION, PTY knob (BX9 model)
q; SURROUND button
qa VOLUME knob
qs PHONES jack
qd ENTER button
qf REC PAUSE/START button and indicator
qg CD SYNC HI-DUB button
qh LOOP button (BX9 model)
KARAOKE PON button (DX9 model)
qj MIC jack (DX9 model)
qk MIC LEVEL knob (DX9 model)
ql V-GROOVE button and indicator
w; CURSOL button and indicator
wa GROOVE button
ws EQ EDIT button
wd SPECTRUM button
wf DISPLAY button
wg ?/1 button and indicator
wh TUNER/BAND button
wj MD (VIDEO) button
wk Y button
wl > + button
e; X button
ea – . button
es x button
ed TAPE A/B button
ef CD button
eg Function indicator
eh m/M knob
Photo: HCD-BX9
