55
Ver 1.2 2001.08
0301 8-820-116-01 OPTICAL PICK-UP KSM-213DAP
302 1-792-024-11 WIRE (FLAT TYPE) (16 CORE)
303 A-4724-934-A BD BOARD, COMPLETE
304 4-951-620-01 SCREW (2.6X8), +BVTP
Ref. No. Part No. Description Remarks
8-7. BASE UNIT SECTION (BU-K2BD38)
302
304
303
301
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
To Next Page
