Sony HCD-BX9 - Page 61

61
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D861 8-719-988-61 DIODE 1SS355TE-17
D891 8-719-988-61 DIODE 1SS355TE-17
D892 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-200-82 DIODE 11ES2-TB5
D902 8-719-200-82 DIODE 11ES2-TB5
D903 8-719-200-82 DIODE 11ES2-TB5
D904 8-719-200-82 DIODE 11ES2-TB5
D906 8-719-200-82 DIODE 11ES2-TB5
D907 8-719-200-82 DIODE 11ES2-TB5
D908 8-719-200-82 DIODE 11ES2-TB5
D909 8-719-200-82 DIODE 11ES2-TB5
D910 8-719-200-82 DIODE 11ES2-TB5
D911 8-719-200-82 DIODE 11ES2-TB5
D952 8-719-988-61 DIODE 1SS355TE-17
D953 8-719-988-61 DIODE 1SS355TE-17
< FERRITE BEAD >
FB201 1-216-295-91 SHORT 0
FB202 1-216-295-91 SHORT 0
FB203 1-216-295-91 SHORT 0
FB204 1-216-295-91 SHORT 0
FB416 1-216-295-91 SHORT 0
FB462 1-216-295-91 SHORT 0
FB499 1-216-295-91 SHORT 0
< FRONT END >
FE601 1-693-477-11 FRONT END (3 GANGS)(DX9)
FE603 1-693-496-11 FRONT END (4 GANG)(BX9)
< IC >
IC101 8-759-652-04 IC M61504FP-TP
IC102 8-759-099-06 IC M5218AFP-TE1
IC104 8-759-099-06 IC M5218AFP-TE1(DX9)
IC201 8-749-923-04 IC TOTX178A(OPTICAL DIGITAL OUT)
IC301 8-759-652-02 IC HA12226F
IC302 8-759-143-54 IC uPC1330HA
IC303 8-759-656-83 IC NJM4580MD-TE
IC304 8-759-656-83 IC NJM4580MD-TE
IC401 8-759-652-48 IC M30622MAA-A25FP
IC501 8-759-635-63 IC M51943BSL-TP
IC601 8-759-652-00 IC BA1450
IC651 8-759-288-54 IC LC72130
IC681 8-759-099-06 IC M5218AFP-TE1(BX9)
IC682 8-759-541-48 IC BU1924(BX9)
IC911 8-759-039-69 IC uPC7805AHF
IC921 8-759-088-08 IC uPC7812AHF
IC931 8-759-071-48 IC TA7807S
IC951 8-759-158-62 IC TA78057S
IC961 8-759-701-59 IC M5F7809L
< IFT >
IFT601 1-435-295-11 TRANSFORMER, IF
< JACK >
J901 1-793-987-11 JACK, PIN 2P(MD/VIDEO)
< JUMPER RESISTOR >
JR1 1-216-296-91 SHORT 0
JR2 1-216-296-91 SHORT 0
JR3 1-216-296-91 SHORT 0
JR4 1-216-296-91 SHORT 0
JR6 1-216-296-91 SHORT 0
JR7 1-216-296-91 SHORT 0
JR8 1-216-295-91 SHORT 0
JR13 1-216-296-91 SHORT 0
JR14 1-216-296-91 SHORT 0
JR15 1-216-296-91 SHORT 0
JR17 1-216-296-91 SHORT 0
JR18 1-216-295-91 SHORT 0
JR19 1-216-296-91 SHORT 0
JR23 1-216-296-91 SHORT 0
JR25 1-216-296-91 SHORT 0
JR26 1-216-296-91 SHORT 0
JR27 1-216-296-91 SHORT 0
JR29 1-216-296-91 SHORT 0
JR31 1-216-295-91 SHORT 0
JR32 1-216-296-91 SHORT 0
JR33 1-216-296-91 SHORT 0
JR34 1-216-295-91 SHORT 0
JR36 1-216-295-91 SHORT 0
JR37 1-216-296-91 SHORT 0
JR38 1-216-296-91 SHORT 0
JR42 1-216-295-91 SHORT 0
JR44 1-216-296-91 SHORT 0
JR51 1-216-296-91 SHORT 0
JR52 1-216-296-91 SHORT 0
JR54 1-216-295-91 SHORT 0
JR140 1-216-296-91 SHORT 0
JR601 1-216-296-91 SHORT 0
JR602 1-216-295-91 SHORT 0
JR603 1-216-296-91 SHORT 0
JR604 1-216-296-91 SHORT 0
JR605 1-216-296-91 SHORT 0
JR606 1-216-296-91 SHORT 0
JR607 1-216-295-91 SHORT 0
JR608 1-216-296-91 SHORT 0
JR609 1-216-295-91 SHORT 0 (DX9)
JR611 1-216-296-91 SHORT 0
JR614 1-216-295-91 SHORT 0 (BX9)
JR615 1-216-295-91 SHORT 0
JR616 1-216-295-91 SHORT 0
JR619 1-216-295-91 SHORT 0
JR634 1-216-295-91 SHORT 0
JR636 1-216-295-91 SHORT 0 (BX9)
JR640 1-216-295-91 SHORT 0 (DX9)
JR641 1-216-295-91 SHORT 0 (BX9)
JR907 1-216-295-91 SHORT 0 (BX9)
JR910 1-216-295-91 SHORT 0 (BX9)
JR912 1-216-296-91 SHORT 0 (DX9)
JR923 1-216-295-91 SHORT 0 (DX9)
JR924 1-216-295-91 SHORT 0 (DX9)
JR928 1-216-295-91 SHORT 0 (DX9)
< COIL >
L201 1-414-189-31 INDUCTOR 100uH
L301 1-410-780-11 INDUCTOR 27mH
L302 1-414-193-41 INDUCTOR 220uH
MAIN
