Sony HCD-BX9 - Variable Resistors and Relays List; Terminals and Vibrators List; Switches and Capacitors List

65
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R901 1-249-405-11 CARBON 100 5% 1/4W F
R911 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R912 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R914 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
0 R916 1-219-120-51 FUSIBLE 0.15 5% 1/4W
R966 1-216-019-00 METAL CHIP 56 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB641 1-234-457-11 ENCAPSULATED COMPONENT
< VARIABLE RESISTOR >
RV301 1-241-764-11 RES, ADJ, CARBON 10K
RV302 1-241-762-11 RES, ADJ, CARBON 2.2K
RV303 1-241-762-11 RES, ADJ, CARBON 2.2K
RV304 1-241-768-11 RES, ADJ, CARBON 220K
RV351 1-241-764-11 RES, ADJ, CARBON 10K
RV352 1-241-762-11 RES, ADJ, CARBON 2.2K
RV353 1-241-762-11 RES, ADJ, CARBON 2.2K
RV354 1-241-768-11 RES, ADJ, CARBON 220K
RV611 1-241-765-11 RES, ADJ, CARBON 22K
< RELAY >
RY801 1-755-372-11 RELAY
< TRANSFORMER >
T301 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
T601 1-435-195-11 TRANSFORMER, DISCRIMINATOR
T602 1-234-477-11 ENCAPSULATED COMPONENT(BX9)
< TERMINAL >
TM601 1-694-555-11 TERMINAL BOARD (4P)(FM/AM)(DX9)
TM601 1-694-556-21 TERMINAL BOARD (ANT.PAL)(FM/AM)(BX9)
TM801 1-694-635-11 TERMINAL BOARD (4P)(SPEAKER)
< VIBRATOR >
X401 1-567-098-41 VIBRATOR, CRYSTAL(32.768kHz)
X402 1-781-107-21 VIBRATOR, CERAMIC(16MHz)
X651 1-760-549-31 VIBRATOR, CRYSTAL(4.5MHz)
X681 1-579-900-21 VIBRATOR, CRYSTAL(4.332MHz)(BX9)
**************************************************************
1-675-910-11 MOTOR BOARD
*************
< CAPACITOR >
C721 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
< CONNECTOR >
CN721 1-770-516-31 CONNECTOR, FFC 8P
CN722 1-785-330-11 PIN, CONNECTOR (LIGHT ANGLE)4P
< SWITCH >
S701 1-771-822-11 SWITCH, LEVER (SLIDE)(OPEN/CLOSE)
**************************************************************
A-4428-075-A PANEL BOARD, COMPLETE (BX9)
**********************
A-4428-338-A PANEL BOARD, COMPLETE (EA)
**********************
A-4428-342-A PANEL BOARD, COMPLETE
**********************
(E,AR,MX,SP,MY,AUS)
4-224-584-11 HOLDER (FL)
< CAPACITOR >
C601 1-124-589-11 ELECT 47uF 20% 16V
C602 1-126-163-11 ELECT 4.7uF 20% 50V
C603 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C604 1-162-294-31 CERAMIC 0.001uF 10% 50V
C605 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C606 1-162-294-31 CERAMIC 0.001uF 10% 50V
C607 1-104-664-11 ELECT 47uF 20.00% 10V
C608 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C609 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C612 1-162-303-11 CERAMIC 0.0033uF 30.00% 16V
C615 1-126-963-11 ELECT 4.7uF 20.00% 50V
C616 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C617 1-162-294-31 CERAMIC 0.001uF 10% 50V
C620 1-126-933-11 ELECT 100uF 20.00% 16V
C621 1-104-664-11 ELECT 47uF 20.00% 16V
C631 1-162-294-31 CERAMIC 0.001uF 10% 50V
C632 1-162-294-31 CERAMIC 0.001uF 10% 50V
C651 1-164-159-21 CERAMIC 0.1uF 50V
C652 1-126-960-11 ELECT 1uF 20.00% 50V
C653 1-126-960-11 ELECT 1uF 20.00% 50V
C654 1-164-159-21 CERAMIC 0.1uF 50V
C655 1-162-282-31 CERAMIC 100PF 10% 50V
C656 1-162-282-31 CERAMIC 100PF 10% 50V
C657 1-162-282-31 CERAMIC 100PF 10% 50V
C658 1-162-282-31 CERAMIC 100PF 10% 50V
C659 1-162-282-31 CERAMIC 100PF 10% 50V
C660 1-162-282-31 CERAMIC 100PF 10% 50V
C661 1-162-282-31 CERAMIC 100PF 10% 50V
C662 1-162-282-31 CERAMIC 100PF 10% 50V
C663 1-162-282-31 CERAMIC 100PF 10% 50V
C664 1-162-282-31 CERAMIC 100PF 10% 50V
C665 1-162-282-31 CERAMIC 100PF 10% 50V
C666 1-162-282-31 CERAMIC 100PF 10% 50V
C667 1-162-282-31 CERAMIC 100PF 10% 50V
C668 1-162-282-31 CERAMIC 100PF 10% 50V
C669 1-162-282-31 CERAMIC 100PF 10% 50V
C670 1-162-282-31 CERAMIC 100PF 10% 50V
C671 1-162-282-31 CERAMIC 100PF 10% 50V
C717 1-126-157-11 ELECT 10uF 20% 16V
(DX9)
C718 1-126-157-11 ELECT 10uF 20% 16V
(DX9)
C719 1-126-961-11 ELECT 2.2uF 20.00% 50V
(DX9)
C720 1-164-159-21 CERAMIC 0.1uF 50V(EA)
C721 1-162-294-31 CERAMIC 0.001uF 10% 50V(EA)
C722 1-162-305-11 CERAMIC 0.0068uF 30.00% 16V(EA)
C723 1-126-960-11 ELECT 1uF 20.00% 50V(EA)
PANELMAIN MOTOR
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
