68
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R735 1-247-885-00 CARBON 180K 5% 1/4W
(DX9)
R736 1-249-429-11 CARBON 10K 5% 1/4W
(DX9)
R737 1-249-437-11 CARBON 47K 5% 1/4W
(EA)
R737 1-247-863-91 CARBON 22K 5% 1/4W
(EXCEPT BX9,EA)
R738 1-249-417-11 CARBON 1K 5% 1/4W F
(DX9)
R739 1-249-441-11 CARBON 100K 5% 1/4W
(DX9)
R740 1-249-417-11 CARBON 1K 5% 1/4W F
(DX9)
R741 1-249-429-11 CARBON 10K 5% 1/4W
(DX9)
R742 1-249-417-11 CARBON 1K 5% 1/4W F
(EA)
R744 1-249-441-11 CARBON 100K 5% 1/4W
(DX9)
R745 1-247-807-31 CARBON 100 5% 1/4W
(DX9)
R746 1-249-417-11 CARBON 1K 5% 1/4W F
(DX9)
R747 1-260-093-11 CARBON 330 5% 1/2W
(EA)
< VARIABLE RESISTOR >
RV721 1-225-739-11 RES, VAR CARBON 50K(ECHO LEVEL)(EA)
RV722 1-225-739-11 RES, VAR CARBON 50K(MIC LEVEL)(DX9)
< SWITCH >
S601 1-418-725-11 ENCODER, ROTARY (12 TYPE)(VOLUME)
S611 1-762-875-21 SWITCH, KEYBOARD(f)
S612 1-762-875-21 SWITCH, KEYBOARD(F)
S613 1-762-875-21 SWITCH, KEYBOARD(V-GROOVE)
S614 1-762-875-21 SWITCH, KEYBOARD(LOOP)
S615 1-762-875-21 SWITCH, KEYBOARD(CD SYNC)
S616 1-762-875-21 SWITCH, KEYBOARD(REC/PAUSE)
S617 1-762-875-21 SWITCH, KEYBOARD(ENTER/NEXT)
S618 1-762-875-21 SWITCH, KEYBOARD(M)
S619 1-762-875-21 SWITCH, KEYBOARD(AMS +)
S620 1-762-875-21 SWITCH, KEYBOARD(PAUSE)
S621 1-762-875-21 SWITCH, KEYBOARD(– AMS)
S623 1-762-875-21 SWITCH, KEYBOARD(h)
S624 1-762-875-21 SWITCH, KEYBOARD(H)
S625 1-762-875-21 SWITCH, KEYBOARD(TAPE A/B)
S626 1-762-875-21 SWITCH, KEYBOARD(STOP)
S627 1-762-875-21 SWITCH, KEYBOARD(CD)
S628 1-762-875-21 SWITCH, KEYBOARD(TUNER/BAND)
S629 1-762-875-21 SWITCH, KEYBOARD(PLAY)
S630 1-762-875-21 SWITCH, KEYBOARD(MD(VIDEO))
S631 1-762-875-21 SWITCH, KEYBOARD(m)
S632 1-762-875-21 SWITCH, KEYBOARD(SURROUND)
S633 1-762-875-21 SWITCH, KEYBOARD(DIRECTION)
S634 1-762-875-21 SWITCH, KEYBOARD(REPEAT)
S635 1-762-875-21 SWITCH, KEYBOARD(PLAY MODE)
S636 1-762-875-21 SWITCH, KEYBOARD(EDIT)
S637 1-762-875-21 SWITCH, KEYBOARD(`/1)
S638 1-762-875-21 SWITCH, KEYBOARD(GROOVE)
S639 1-762-875-21 SWITCH, KEYBOARD(EQ EDIT)
S640 1-762-875-21 SWITCH, KEYBOARD(SPECTRUM)
S641 1-762-875-21 SWITCH, KEYBOARD(DISPLAY)
< VIBRATOR >
X601 1-579-352-11 VIBRATOR, CERAMIC(12.5MHz)
**************************************************************
A-4428-503-A POWER AMP BOARD, COMPLETE (BX9)
***************************
A-4428-509-A POWER AMP BOARD, COMPLETE (DX9)
***************************
< CAPACITOR >
C501 1-126-963-11 ELECT 4.7uF 20.00% 50V
C502 1-162-290-31 CERAMIC 470PF 10% 50V
C503 1-162-286-21 CERAMIC 220PF 10.00% 50V
(DX9)
C504 1-104-665-11 ELECT 100uF 20.00% 10V
C507 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C508 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C509 1-128-560-11 ELECT 22uF 20.00% 100V
C510 1-128-578-11 ELECT 1uF 20.00% 100V
C511 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
C512 1-162-306-11 CERAMIC 0.01uF 30.00% 16V
(BX9)
C541 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C542 1-127-752-11 ELECT 3300uF 20% 63V
C544 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C545 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C546 1-127-755-11 ELECT 3300uF 20% 100V
(DX9)
C546 1-127-754-11 ELECT 3300uF 20% 80V
(BX9)
C551 1-126-963-11 ELECT 4.7uF 20.00% 50V
C552 1-162-290-31 CERAMIC 470PF 10% 50V
C553 1-162-286-21 CERAMIC 220PF 10.00% 50V
(DX9)
C554 1-104-665-11 ELECT 100uF 20.00% 10V
C557 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C558 1-136-495-11 MYLAR 0.068uF 5.00% 50V
C559 1-128-560-11 ELECT 22uF 20.00% 100V
C581 1-126-967-11 ELECT 47uF 20.00% 50V
C591 1-136-165-00 MYLAR 0.1uF 5.00% 50V
C592 1-127-752-11 ELECT 3300uF 20% 63V
C596 1-127-755-11 ELECT 3300uF 20% 100V
(DX9)
C596 1-127-754-11 ELECT 3300uF 20% 80V
(BX9)
C942 1-126-964-11 ELECT 10uF 20.00% 50V
C943 1-126-968-11 ELECT 100uF 20.00% 50V
C980 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN502 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
CN503 1-778-981-11 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D501 8-719-991-33 DIODE 1SS133T-77
D502 8-719-991-33 DIODE 1SS133T-77
D503 8-719-922-03 DIODE MTZJ-T-77-18C(DX9)
D503 8-719-110-41 DIODE MTZJ-T-77-15B(BX9)
PANEL
POWER AMP
To Next Page
