Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
71
< DIODE >
D851 8-719-074-42 DIODE SLR325VR-T31
D852 8-719-050-06 DIODE SLR-325MGT31
D853 8-719-050-06 DIODE SLR-325MGT31
D854 8-719-064-11 DIODE SPR-325MVW
D855 8-719-075-50 DIODE SELS6B14C-TP5
D856 8-719-074-42 DIODE SLR325VR-T31
D860 8-719-074-40 DIODE SLR325DU-T31
< IC >
IC802 8-742-132-00 IC SBX1976-51P
< JUMPER RESISTOR >
JR801 1-216-296-91 SHORT 0
JR802 1-216-296-91 SHORT 0
JR803 1-216-296-91 SHORT 0
JR804 1-216-296-91 SHORT 0
JR805 1-216-296-91 SHORT 0
JR806 1-216-296-91 SHORT 0
JR807 1-216-296-91 SHORT 0
JR809 1-216-296-91 SHORT 0
JR810 1-216-296-91 SHORT 0
JR811 1-216-296-91 SHORT 0
JR812 1-216-296-91 SHORT 0
JR813 1-216-296-91 SHORT 0
JR818 1-216-296-91 SHORT 0
JR822 1-216-296-91 SHORT 0
JR823 1-216-296-91 SHORT 0
JR824 1-216-296-91 SHORT 0
JR825 1-216-296-91 SHORT 0
JR841 1-216-296-91 SHORT 0
JR842 1-216-296-91 SHORT 0
JR843 1-216-296-91 SHORT 0
JR845 1-216-296-91 SHORT 0
JR846 1-216-296-91 SHORT 0
JR847 1-216-296-91 SHORT 0
JR848 1-216-296-91 SHORT 0
JR849 1-216-296-91 SHORT 0
JR851 1-216-296-91 SHORT 0
JR852 1-216-296-91 SHORT 0
JR853 1-216-296-91 SHORT 0
< TRANSISTOR >
Q851 8-729-038-67 TRANSISTOR KRC102S
Q852 8-729-038-67 TRANSISTOR KRC102S
Q853 8-729-038-67 TRANSISTOR KRC102S
Q854 8-729-038-67 TRANSISTOR KRC102S
Q855 8-729-038-67 TRANSISTOR KRC102S
Q856 8-729-038-67 TRANSISTOR KRC102S
Q857 8-729-038-67 TRANSISTOR KRC102S
Q861 8-729-038-67 TRANSISTOR KRC102S
Q870 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R602 1-216-045-00 METAL CHIP 680 5% 1/10W
R603 1-216-047-91 RES-CHIP 820 5% 1/10W
R604 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R605 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R606 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R607 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R610 1-216-045-00 METAL CHIP 680 5% 1/10W
R611 1-216-047-91 RES-CHIP 820 5% 1/10W
R612 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R613 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R614 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R615 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R616 1-216-079-00 METAL CHIP 18K 5% 1/10W
R641 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R642 1-216-039-00 METAL CHIP 390 5% 1/10W
R643 1-216-039-00 METAL CHIP 390 5% 1/10W
R645 1-216-029-00 METAL CHIP 150 5% 1/10W
R646 1-216-037-00 METAL CHIP 330 5% 1/10W
R647 1-216-033-00 METAL CHIP 220 5% 1/10W
R648 1-216-073-00 METAL CHIP 10K 5% 1/10W
R649 1-216-033-00 METAL CHIP 220 5% 1/10W
R650 1-216-029-00 METAL CHIP 150 5% 1/10W
R660 1-216-041-00 METAL CHIP 470 5% 1/10W
< VARIABLE RESISTOR >
RV801 1-473-392-11 ENCODER, ROTARY (VOLUME)
RV802 1-418-859-11 ENCODER, ROTARY (TREBLE)
RV803 1-418-859-11 ENCODER, ROTARY (BASS)
< SWITCH >
S801 1-571-760-11 SWITCH, KEY BOARD (?/1)
S802 1-571-760-11 SWITCH, KEY BOARD (SYNCRO REC)
S803 1-571-760-11 SWITCH, KEY BOARD (ENTER/START)
S804 1-571-760-11 SWITCH, KEY BOARD (FUNCTION)
S805 1-571-760-11 SWITCH, KEY BOARD
(PLAY MODE/DIRECTION)
S806 1-571-760-11 SWITCH, KEY BOARD (REPEAT DOLBY NR)
S807 1-571-760-11 SWITCH, KEY BOARD (MD REC z)
S809 1-571-760-11 SWITCH, KEY BOARD (TAPE Y)
S810 1-571-760-11 SWITCH, KEY BOARD (TAPE x)
S811 1-571-760-11 SWITCH, KEY BOARD (TAPE REC z )
S812 1-571-760-11 SWITCH, KEY BOARD (TAPE X)
S813 1-571-760-11 SWITCH, KEY BOARD (DSG)
S814 1-571-760-11 SWITCH, KEY BOARD (MD Z)
S815 1-571-760-11 SWITCH, KEY BOARD (MD u )
S816 1-571-760-11 SWITCH, KEY BOARD (MD x)
************************************************************
A-4473-145-A CONTROL (B) BOARD, COMPLETE
***************************
< CAPACITOR >
C132 1-124-584-00 ELECT 100uF 20% 10V
C134 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C232 1-124-584-00 ELECT 100uF 20% 10V
C234 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
< CONNECTOR >
CN803 1-794-469-11 CONNECTOR, BOARD TO BOARD
< DIODE >
D857 8-719-064-11 DIODE SPR-325MVW
D858 8-719-075-51 DIODE SELS6B14C-LF62
CONTROL (A) CONTROL (B)
