Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
72
< FERRITE BEAD >
FB102 1-469-144-21 FERRITE 0UH
FB202 1-469-144-21 FERRITE 0UH
< JACK >
J301 1-794-453-11 JACK (PHONES)
< JUMPER RESISTOR >
JR831 1-216-296-91 SHORT 0
JR832 1-216-296-91 SHORT 0
JR833 1-216-296-91 SHORT 0
JR834 1-216-296-91 SHORT 0
JR835 1-216-296-91 SHORT 0
< COIL >
L102 1-412-006-31 INDUCTOR CHIP 10uH
L202 1-412-006-31 INDUCTOR CHIP 10uH
< TRANSISTOR >
Q132 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q232 8-729-920-31 TRANSISTOR DTC343TK-T-146
Q859 8-729-038-67 TRANSISTOR KRC102S
Q860 8-729-038-67 TRANSISTOR KRC102S
Q862 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R128 1-216-005-00 METAL CHIP 15 5% 1/10W
R139 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R228 1-216-005-00 METAL CHIP 15 5% 1/10W
R239 1-216-065-91 RES-CHIP 4.7K 5% 1/10W
R618 1-216-045-00 METAL CHIP 680 5% 1/10W
R619 1-216-047-91 RES-CHIP 820 5% 1/10W
R620 1-216-051-00 METAL CHIP 1.2K 5% 1/10W
R621 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R622 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R652 1-216-029-00 METAL CHIP 150 5% 1/10W
R653 1-216-033-00 METAL CHIP 220 5% 1/10W
R662 1-216-029-00 METAL CHIP 150 5% 1/10W
< SWITCH >
S817 1-571-760-11 SWITCH, KEY BOARD (CD Z)
S818 1-571-760-11 SWITCH, KEY BOARD (CD u )
S819 1-571-760-11 SWITCH, KEY BOARD (CD x)
S820 1-571-760-11 SWITCH, KEY BOARD (CD >)
S821 1-571-760-11 SWITCH, KEY BOARD (CD .)
S822 1-571-760-11 SWITCH, KEY BOARD (TUNER/BAND)
************************************************************
A-4473-149-A DIGITAL BOARD, COMPLETE
***********************
< CAPACITOR >
C171 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C172 1-124-584-00 ELECT 100uF 20% 10V
C201 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C202 1-163-227-11 CERAMIC CHIP 10PF 0.50PF 50V
C203 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C216 1-124-584-00 ELECT 100uF 20% 10V
C218 1-124-261-00 ELECT 10uF 20% 50V
C219 1-124-261-00 ELECT 10uF 20% 50V
C220 1-124-261-00 ELECT 10uF 20% 50V
C221 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C222 1-124-261-00 ELECT 10uF 20% 50V
C341 1-124-589-11 ELECT 47uF 20% 16V
C350 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C351 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C352 1-124-584-00 ELECT 100uF 20% 10V
C353 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C355 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C357 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C358 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C359 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C360 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C362 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C363 1-163-251-11 CERAMIC CHIP 100PF 5.00% 50V
C503 1-124-584-00 ELECT 100uF 20% 10V
C509 1-124-584-00 ELECT 100uF 20% 10V
C510 1-124-584-00 ELECT 100uF 20% 10V
C522 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C527 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C528 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C529 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C818 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C819 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C2001 1-163-038-91 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
* CN101 1-565-650-11 SOCKET, CONNECTOR 25P
CN103 1-794-474-11 CONNECTOR, FFC/FPC
CN104 1-793-601-11 CONNECTOR, FFC/FPC (ZIF) 21P
< FERRITE BEAD >
FB801 1-469-144-21 FERRITE 0UH
FB802 1-469-144-21 FERRITE 0UH
< IC >
IC153 8-759-481-19 IC LB1830M-S-TE-L
IC201 8-759-553-65 IC UDA1341TS
IC202 8-759-564-53 IC MC74HCU04ADTR2
IC316 8-759-657-09 IC M30624MG-A16FP
< JUMPER RESISTOR >
JR503 1-216-295-91 SHORT 0
JR504 1-216-296-91 SHORT 0
JR506 1-216-296-91 SHORT 0
JR508 1-216-295-91 SHORT 0
JR510 1-216-296-91 SHORT 0
JR512 1-216-296-91 SHORT 0
JR514 1-216-296-91 SHORT 0
JR516 1-216-296-91 SHORT 0
JR518 1-216-296-91 SHORT 0
JR519 1-216-296-91 SHORT 0
JR520 1-216-295-91 SHORT 0
JR521 1-216-295-91 SHORT 0
JR522 1-216-295-91 SHORT 0
JR525 1-216-296-91 SHORT 0
JR526 1-216-296-91 SHORT 0
CONTROL (B)
DIGITAL
