Sony HCD-CP33 - Page 73

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
73
JR528 1-216-296-91 SHORT 0
JR529 1-216-296-91 SHORT 0
JR530 1-216-296-91 SHORT 0
JR531 1-216-295-91 SHORT 0
JR533 1-216-296-91 SHORT 0
JR534 1-216-296-91 SHORT 0
JR535 1-216-295-91 SHORT 0
JR536 1-216-295-91 SHORT 0
JR537 1-216-296-91 SHORT 0
JR538 1-216-295-91 SHORT 0
JR539 1-216-296-91 SHORT 0
JR540 1-216-296-91 SHORT 0
JR541 1-216-296-91 SHORT 0
JR542 1-216-296-91 SHORT 0
< TRANSISTOR >
Q350 8-729-038-67 TRANSISTOR KRC102S
< RESISTOR >
R201 1-216-121-91 RES-CHIP 1M 5% 1/10W
R202 1-216-041-00 METAL CHIP 470 5% 1/10W
R203 1-216-049-91 RES-CHIP 1K 5% 1/10W
R204 1-216-089-91 RES-CHIP 47K 5% 1/10W
R205 1-216-113-00 METAL CHIP 470K 5% 1/10W
R206 1-216-041-00 METAL CHIP 470 5% 1/10W
R207 1-216-041-00 METAL CHIP 470 5% 1/10W
R210 1-216-037-00 METAL CHIP 330 5% 1/10W
R330 1-216-073-00 METAL CHIP 10K 5% 1/10W
R331 1-216-246-00 RES-CHIP 100K 5% 1/8W
R333 1-216-222-00 RES-CHIP 10K 5% 1/8W
R349 1-216-073-00 METAL CHIP 10K 5% 1/10W
R351 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R352 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R353 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R358 1-216-073-00 METAL CHIP 10K 5% 1/10W
R361 1-216-073-00 METAL CHIP 10K 5% 1/10W
R363 1-216-222-00 RES-CHIP 10K 5% 1/8W
R366 1-216-097-91 RES-CHIP 100K 5% 1/10W
R367 1-216-097-91 RES-CHIP 100K 5% 1/10W
R370 1-216-073-00 METAL CHIP 10K 5% 1/10W
R371 1-216-073-00 METAL CHIP 10K 5% 1/10W
R383 1-216-073-00 METAL CHIP 10K 5% 1/10W
R384 1-216-073-00 METAL CHIP 10K 5% 1/10W
R385 1-216-073-00 METAL CHIP 10K 5% 1/10W
R386 1-216-073-00 METAL CHIP 10K 5% 1/10W
R391 1-216-073-00 METAL CHIP 10K 5% 1/10W
R395 1-216-073-00 METAL CHIP 10K 5% 1/10W
R400 1-216-073-00 METAL CHIP 10K 5% 1/10W
R816 1-216-174-00 RES-CHIP 100 5% 1/8W
R817 1-216-174-00 RES-CHIP 100 5% 1/8W
R818 1-216-174-00 RES-CHIP 100 5% 1/8W
R819 1-216-174-00 RES-CHIP 100 5% 1/8W
R2002 1-216-222-00 RES-CHIP 10K 5% 1/8W
R2004 1-216-174-00 RES-CHIP 100 5% 1/8W
R2005 1-216-174-00 RES-CHIP 100 5% 1/8W
R2006 1-216-174-00 RES-CHIP 100 5% 1/8W
R2007 1-216-025-91 RES-CHIP 100 5% 1/10W
R2008 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2009 1-216-222-00 RES-CHIP 10K 5% 1/8W
< VIBRATOR >
X201 1-781-581-11 VIBRATOR, CRYSTAL 22.5MHz
X302 1-579-175-11 VIBRATOR, CERAMIC 10MHz
************************************************************
1-677-895-11 LCD BOARD
**********
< CAPACITOR >
C603 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN802 1-794-473-11 CONNECTOR, FFC/FPC
< DIODE >
D601 8-719-075-51 DIODE SELS6B14C-LF62
D602 8-719-075-51 DIODE SELS6B14C-LF62
D603 8-719-075-51 DIODE SELS6B14C-LF62
D604 8-719-075-51 DIODE SELS6B14C-LF62
< JUMPER RESISTOR >
JR601 1-216-296-91 SHORT 0
< COIL >
L601 1-412-002-31 INDUCTOR CHIP 4.7uH
L602 1-412-006-31 INDUCTOR CHIP 10uH
< LIQUID CRYSTAL DISPLAY >
LCD801 1-804-070-11 DISPLAY PANEL, LIQUID CRYSTAL
************************************************************
1-676-599-11 LOADING BOARD
************
< CONNECTOR >
* CN1 1-568-943-11 PIN, CONNECTOR 5P
< MOTOR >
M901 A-4672-891-A MOTOR (LD) ASSY (OPEN/CLOSE)
< SWITCH >
S1 1-771-799-11 SWITCH, LEVER (SLIDE)
************************************************************
A-4473-153-A MAIN BOARD, COMPLETE (US,CND)
********************
A-4473-152-A MAIN BOARD, COMPLETE (AEP,UK,AED)
********************
A-4473-144-A MAIN BOARD, COMPLETE
(E,JE,AR,SP,MY,TH,TW,KR,HK,AUS)
********************
* 4-217-354-01 BUSHING, INSULATING
4-931-757-31 SCREW(DIA.2.6X8)(IT3B),TAPPING
7-685-546-14 SCREW+BTP 3X8 TYPE2 N-S
< BATTERY >
BT301 1-528-938-11 BATTERY, LITHIUM ION SECONDARY
LCD
DIGITAL
MAIN
LOADING
