Sony HCD-CPX1 - 3-7. CD MECHANISM DECK (CDM55 A-K6 BD44 S)

HCD-CPX1
13
3-6. TUNER UNIT
3-7. CD MECHANISM DECK (CDM55A-K6BD44S)
2 two screws
(BVTP3
× 6)
3 bracket
5 two screws
(BVTP3
× 6)
1 connector
(CN990)
2 two screws
(BVTP3
× 6)
6 tuner unit
4 wire (flat type) (11 core
)
3 screw
4 two bosses
8 wire (flat type) (21 core
)
(CN1101)
7
5
6 two claws
9 CD mechanism deck
(CDM55A-K6BD44S)
2 CD lid
1 two claws
