Sony HCD-CPX1 - Base Unit (BU-K6 BD44 S); Motor Gear Assy (Sled) (M102), BD Board

HCD-CPX1
15
3-10. BASE UNIT (BU-K6BD44S)
1 two floating screws
(PTPWHM2.6)
5 two insulators
4
5 two insulators
6 base unit
(BU-K6BD44S)
3 two stoppers (BU)
2 two screws
(BTTP M2.6)
1 Remove two
solders.
4 BD board
8 two screws
(M2
× 3)
5 claw
6 gear (A)
7 gear (B)
3 wire (flat type) (16 core
)
(CN102)
9 motor gear assy (SLED)
(M102)
1 Remove two solders.
2
3-11. MOTOR GEAR ASSY (SLED) (M102), BD BOARD
