HCD-CPX1
16
2
sled shaft
1
Slide the lever
in the direction of arrow
A
.
3
Remove the optical pick-up
(KSS-213D) in the direction
of arrow
B
.
A
B
3-12. OPTICAL PICK-UP (KSS-213D)
