56
HCD-CPX1
SECTION 8
ELECTRICAL PARTS LIST
AMP
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4731-313-A AMP BOARD, COMPLETE
********************
7-685-645-79 SCREW +BVTP 3X6 TYPE2 TT (B)
< CAPACITOR/SHORT >
C600 1-128-549-11 ELECT 3300uF 20% 35V
C601 1-104-665-11 ELECT 100uF 20% 10V
C602 1-126-964-11 ELECT 10uF 20% 50V
C603 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C606 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C607 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C608 1-126-964-11 ELECT 10uF 20% 50V
C609 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C610 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C611 1-126-960-11 ELECT 1uF 20% 50V
C612 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C613 1-216-864-11 SHORT CHIP 0
C614 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C615 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C616 1-128-551-11 ELECT 22uF 20% 25V
C617 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C618 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C619 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C620 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C621 1-126-960-11 ELECT 1uF 20% 50V
C622 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C623 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C625 1-126-963-11 ELECT 4.7uF 20% 50V
C628 1-126-963-11 ELECT 4.7uF 20% 50V
C629 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C630 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C631 1-126-963-11 ELECT 4.7uF 20% 50V
C632 1-104-665-11 ELECT 100uF 20% 10V
C633 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C634 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C635 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C636 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C637 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C638 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C639 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C640 1-104-665-11 ELECT 100uF 20% 10V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C648 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C649 1-104-665-11 ELECT 100uF 20% 10V
C650 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C651 1-137-372-11 MYLAR 0.022uF 5% 50V
C652 1-104-665-11 ELECT 100uF 20% 10V
C653 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C654 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C655 1-137-807-31 ELECT 100uF 20% 50V
C656 1-131-704-11 FILM 1uF 5% 50V
C659 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C660 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C661 1-137-372-11 MYLAR 0.022uF 5% 50V
C663 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C666 1-131-704-11 FILM 1uF 5% 50V
C668 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C669 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C670 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C671 1-137-372-11 MYLAR 0.022uF 5% 50V
C672 1-104-665-11 ELECT 100uF 20% 10V
C673 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C674 1-216-864-11 SHORT CHIP 0
C675 1-137-807-31 ELECT 100uF 20% 50V
C676 1-131-704-11 FILM 1uF 5% 50V
C678 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C679 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C680 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C681 1-137-372-11 MYLAR 0.022uF 5% 50V
C682 1-104-665-11 ELECT 100uF 20% 10V
C683 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C686 1-131-704-11 FILM 1uF 5% 50V
C689 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C690 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C692 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C693 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C694 1-164-346-11 CERAMIC CHIP 1uF 16V
C697 1-216-864-11 SHORT CHIP 0
C698 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C699 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
* CN600 1-564-508-11 PLUG, CONNECTOR 5P
CN601 1-568-838-11 CONNECTOR, FFC 21P
• Abbreviation
AUS : Australian model
CND : Canadian model
KR : Korean model
SP : Singapore model
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
