HCD-CPX1
3030
ws IC501 qd (X-OUT)
wa IC401 qa (XCOUT)
2.2 Vp-
30.5 µs
2 Vp-p
62.5 ns
• Waveforms
– BD Board –
0.9
±
0.4 Vp-
1 IC103 qg (RFAC) (CD play mode)
1.7 Vp-p
7.6
µ
s
2 IC101 wh (MDP) (CD play mode)
0.4 Vp-
3 IC101 el (FE) (CD play mode)
0.3 Vp-p
4 IC101 ra (TE) (CD play mode)
0.8
±
0.4 Vp-
5 IC101 rd (RFDC) (CD play mode)
1.9 Vp-
59.1 ns
12 Vp-
12.8 µs
qa Q642, 643 (Collector) (REC mode)
6 IC101 yj (XTAO)
– TC Board – – MAIN Board –
ed IC604 6
ea IC603 q; (LRCK)
– AMP Board –
3.3 Vp-
20.7 µs
3.4 Vp-
326 ns
es IC603 qa (BCK)
2 Vp-p
81.4 ns
– LCD Board –
ra IC803 3 (OSC2)
3.6 Vp-
27.3 µs
