HCD-CPX1
TAPE MECHANICAL DECK SERVICE POSITION
Set up the service position with putting an insulator under the mechanical deck as the figure shown below.
tape mechanical deck
insulator
CD MECHANISM DECK SERVICE POSITION
Set up the service position for the CD mechanism deck with disassembling the entire set as the figure shown below.
AMP section
CD mechanism deck
main board
