Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
59
HCD-CPX1
R192 1-216-839-11 METAL CHIP 33K 5% 1/10W
R193 1-216-847-11 METAL CHIP 150K 5% 1/10W
R194 1-216-843-11 METAL CHIP 68K 5% 1/10W
R195 1-216-851-11 METAL CHIP 330K 5% 1/10W
R196 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R197 1-216-821-11 METAL CHIP 1K 5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RN101 1-233-576-11 RES, CHIP NETWORK 100
< SWITCH >
S101 1-771-853-11 SWITCH, DETECTION (LIMIT)
< VIBRATOR >
X101 1-579-280-11 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
HP BOARD
*********
< CAPACITOR >
C817 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C818 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C820 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< SHORT >
FB801 1-216-864-11 SHORT CHIP 0
FB802 1-216-864-11 SHORT CHIP 0
FB803 1-216-864-11 SHORT CHIP 0
< JACK >
J801 1-815-603-11 JACK (PHONES)
**************************************************************
1-686-791-11 LCD BOARD
**********
4-244-028-01 HOLDER (LCD)
< CAPACITOR >
C801 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C803 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C804 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C805 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C806 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C841 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C842 1-162-974-11 CERAMIC CHIP 0.01uF 50V
< CONNECTOR >
CN802 1-784-731-11 CONNECTOR, FFC 9P
CN803 1-770-010-21 CONNECTOR, BOARD TO BOARD 4P
< IC >
IC803 6-703-289-01 IC BU9728AKS
< LIQUID CRYSTAL DISPLAY >
LCD801 1-805-113-11 DISPLAY PANEL, LIQUID CRYSTAL
< RESISTOR >
R801 1-216-853-11 METAL CHIP 470K 5% 1/10W
R805 1-216-849-11 METAL CHIP 220K 5% 1/10W
R806 1-216-809-11 METAL CHIP 100 5% 1/10W
R807 1-216-809-11 METAL CHIP 100 5% 1/10W
R808 1-216-809-11 METAL CHIP 100 5% 1/10W
R809 1-216-809-11 METAL CHIP 100 5% 1/10W
R810 1-216-809-11 METAL CHIP 100 5% 1/10W
R841 1-216-817-11 METAL CHIP 470 5% 1/10W
R842 1-216-817-11 METAL CHIP 470 5% 1/10W
R843 1-216-817-11 METAL CHIP 470 5% 1/10W
R844 1-216-817-11 METAL CHIP 470 5% 1/10W
R845 1-216-817-11 METAL CHIP 470 5% 1/10W
R846 1-216-817-11 METAL CHIP 470 5% 1/10W
**************************************************************
1-674-336-12 LOADING BOARD
**************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-786-203-11 SWITCH, LEVER (SLIDE)
(LOADING IN/OUT DETECT)
**************************************************************
A-4731-299-A MAIN BOARD, COMPLETE (SP, KR)
A-4731-302-A MAIN BOARD, COMPLETE (US, CND)
A-4731-355-A MAIN BOARD, COMPLETE (AUS)
*********************
7-685-645-79 SCREW +BVTP 3X6 TYPE2 TT (B)
< CAPACITOR >
C101 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C102 1-126-960-11 ELECT 1uF 20% 50V
C103 1-126-960-11 ELECT 1uF 20% 50V
C104 1-126-960-11 ELECT 1uF 20% 50V
C105 1-126-960-11 ELECT 1uF 20% 50V
C106 1-126-960-11 ELECT 1uF 20% 50V
C107 1-126-960-11 ELECT 1uF 20% 50V
C108 1-130-476-00 MYLAR 0.0027uF 5% 50V
C109 1-130-496-00 MYLAR 0.12uF 5% 50V
C110 1-130-496-00 MYLAR 0.12uF 5% 50V
C111 1-126-964-11 ELECT 10uF 20% 50V
C121 1-126-964-11 ELECT 10uF 20% 50V
C122 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C123 1-126-964-11 ELECT 10uF 20% 50V
C124 1-126-934-11 ELECT 220uF 20% 10V
C131 1-104-665-11 ELECT 100uF 20% 16V
C132 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C133 1-104-665-11 ELECT 100uF 20% 10V
C141 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C151 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
BD HP LCD LOADING MAIN
