HCD-CPX1
CLINCHING THE WIRE (FLAT TYPE) (21 CORE)
HANDLING TWO CABLES FROM THE SUB POWER AND THE SWITCHING REGULATOR TO THE MAIN BOARD
heat sink
AMP board
Clinch the wire (flat type) (21 core)
to prevent the wire from contacting with
the heat sink of the AMP board.
cable from the switching
regulator to the main board
lead pin
cable from the sub power
to the main board
fabric no woven (10 – 20)
Note: Do not reuse the current fabri
because it may fall off.
Note: Fix two cables with the lead pin and the fabric non woven (10 – 20),
or they may sag and contact with the CD mechanism deck.
