— 96 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D637 8-719-057-09 DIODE LNJ801LPDJA (AUTO PLAY)
< RESISTOR >
R553 1-249-411-11 CARBON 330 5% 1/4W
R554 1-249-413-11 CARBON 470 5% 1/4W F
R555 1-249-415-11 CARBON 680 5% 1/4W F
R556 1-249-417-11 CARBON 1K 5% 1/4W F
R557 1-249-419-11 CARBON 1.5K 5% 1/4W F
R678 1-247-815-91 CARBON 220 5% 1/4W
R680 1-247-815-91 CARBON 220 5% 1/4W
< SWITCH >
S554 1-554-303-21 SWITCH, TACTILE (·)
S555 1-554-303-21 SWITCH, TACTILE (π )
S556 1-554-303-21 SWITCH, TACTILE (∏)
S557 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
S558 1-554-303-21 SWITCH, TACTILE (AUTO PLAY)
**************************************************************
* 1-659-405-11 CD JOG BOARD
************
< CAPACITOR >
C515 1-162-306-11 CERAMIC 0.01uF 30% 16V
C516 1-162-306-11 CERAMIC 0.01uF 30% 16V
< CONNECTOR >
* CN518 1-568-942-11 PIN, CONNECTOR 4P
< RESISTOR >
R558 1-249-421-11 CARBON 2.2K 5% 1/4W F
R559 1-249-423-11 CARBON 3.3K 5% 1/4W F
R560 1-249-427-11 CARBON 6.8K 5% 1/4W F
R561 1-249-431-11 CARBON 15K 5% 1/4W
< SWITCH >
S502 1-473-534-11 ENCODER, ROTARY (≠ AMS ± )
S559 1-554-303-21 SWITCH, TACTILE (PROGRAM)
S560 1-554-303-21 SWITCH, TACTILE (REPEAT)
S561 1-554-303-21 SWITCH, TACTILE (SHUFFLE)
S562 1-554-303-21 SWITCH, TACTILE (CONTINUE)
**************************************************************
* 1-659-406-11 CD LED BOARD
************
< CONNECTOR >
CN516 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D3151 8-719-057-40 DIODE HLMF-K305-2UL (5CD)
D3152 8-719-058-19 DIODE HLMF-K405-2UL (5CD)
D3153 8-719-058-19 DIODE HLMF-K405-2UL (5CD)
D3154 8-719-057-40 DIODE HLMF-K305-2UL (5CD)
< RESISTOR >
R3151 1-249-412-11 CARBON 390 5% 1/4W F
**************************************************************
* A-4673-765-A CD MOTOR BOARD, COMPLETE
************************
* 4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-124-907-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-124-907-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< MOTOR >
M201 A-4660-977-A MOTOR ASSY (TABLE)
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY)(UP)
**************************************************************
* 1-659-408-11 DOOR SW BOARD
*************
< CAPACITOR >
C591 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
* CN519 1-506-481-11 PIN, CONNECTOR 2P
CD (R)
CD JOG
DOOR SW
CD LED CD MOTOR
