— 97 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< SWITCH >
S591 1-572-126-11 SWITCH, PUSH (1 KEY)(6 OPEN)
**************************************************************
* 1-659-411-11 HP BOARD
********
< CAPACITOR >
C621 1-162-294-31 CERAMIC 1000PF 50V
(N555AV:AEP,UK,G,IT)
C622 1-162-294-31 CERAMIC 1000PF 50V
(N555AV:AEP,UK,G,IT)
C623 1-164-159-21 CERAMIC 0.1uF 50V
C624 1-164-159-21 CERAMIC 0.1uF 50V
< JACK >
J601 1-569-113-11 JACK, LARGE TYPE (PHONES)
**************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA-H2
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR NJL5165KA-H2
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W F
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY)(A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY)(B PLAY)
S1003 1-572-248-11 SWITCH, LEAF (A HALF)
S1004 1-571-281-21 SWITCH, LEAF (A CrO2)
S1005 1-571-281-21 SWITCH, LEAF (REC A)
S1006 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
**************************************************************
* 1-659-059-13 LED BOARD
*********
< DIODE >
D201 8-719-032-98 DIODE SEL5820A (DISC No.)
< TRANSISTOR >
Q201 8-729-119-78 TRANSISTOR 2SC2785-HFE
< RESISTOR >
R201 1-247-863-91 CARBON 22K 5% 1/4W
R202 1-249-411-11 CARBON 330 5% 1/4W
R203 1-249-437-11 CARBON 47K 5% 1/4W
**************************************************************
* A-4389-602-A MAIN BOARD, COMPLETE (D670AV)
*****************************
* A-4389-615-A MAIN BOARD, COMPLETE (N555AV:E,MX,AR)
*************************************
* A-4389-622-A MAIN BOARD, COMPLETE (N555AV:AEP,UK)
************************************
* A-4389-894-A MAIN BOARD, COMPLETE (N555AV:AUS,PX)
************************************
* A-4390-010-A MAIN BOARD, COMPLETE (N555AV:G,IT)
**********************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C201 1-124-925-11 ELECT 2.2uF 20% 100V
C202 1-130-479-00 MYLAR 0.0047uF 5% 50V
C203 1-126-925-11 ELECT 470uF 20% 10V
C211 1-124-925-11 ELECT 2.2uF 20% 100V
C212 1-130-479-00 MYLAR 0.0047uF 5% 50V
C250 1-162-306-11 CERAMIC 0.01uF 20% 16V
(N555AV:AEP,UK,G,IT)
C251 1-164-035-11 CERAMIC 47PF 5% 50V
(N555AV:AEP,UK,G,IT)
C252 1-102-527-11 CERAMIC 82PF 5% 50V
(N555AV:AEP,UK,G,IT)
C253 1-162-291-31 CERAMIC 560PF 10% 50V
(N555AV:AEP,UK,G,IT)
C254 1-162-306-11 CERAMIC 0.01uF 20% 16V
(N555AV:AEP,UK,G,IT)
C255 1-162-288-31 CERAMIC 330PF 10% 50V
(N555AV:AEP,UK,G,IT)
C256 1-124-925-11 ELECT 2.2uF 20% 100V
(N555AV:AEP,UK,G,IT)
C257 1-126-964-11 ELECT 10uF 20% 50V
(N555AV:AEP,UK,G,IT)
MAIN
HP
LED
LEAF SWITCH
DOOR SW
