— 100 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C1156 1-126-964-11 ELECT 10uF 20% 50V
C1157 1-162-306-11 CERAMIC 0.01uF 30% 16V
C1158 1-162-286-21 CERAMIC 220PF 10% 50V
C1160 1-126-964-11 ELECT 10uF 20% 50V
C1161 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1162 1-126-964-11 ELECT 10uF 20% 50V
C1163 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1164 1-126-964-11 ELECT 10uF 20% 50V
C1165 1-126-964-11 ELECT 10uF 20% 50V
C1166 1-126-964-11 ELECT 10uF 20% 50V
C1167 1-126-964-11 ELECT 10uF 20% 50V
C1168 1-162-286-21 CERAMIC 220PF 10% 50V
C1169 1-109-889-11 ELECT 1uF 20% 50V
C1178 1-162-294-31 CERAMIC 0.001uF 10% 50V
C9001 1-162-306-11 CERAMIC 0.01uF 30% 16V
C9003 1-162-294-31 CERAMIC 0.001uF 10% 50V
C9004 1-162-294-31 CERAMIC 0.001uF 10% 50V
C9005 1-162-282-31 CERAMIC 100PF 10% 50V
C9006 1-164-159-21 CERAMIC 0.1uF 50V
C9007 1-162-294-31 CERAMIC 0.001uF 10% 50V
C9008 1-162-294-31 CERAMIC 0.001uF 10% 50V
< CONNECTOR >
CN201 1-770-067-11 CONNECTOR, FFC/FPC 19P
* CN203 1-568-936-21 PIN, CONNECTOR 9P
* CN250 1-568-832-11 SOCKET, CONNECTOR 13P
(D670AV/N555AV:E,AUS,PX,MX,AR)
* CN250 1-568-834-11 SOCKET, CONNECTOR 15P (N555AV:AEP,UK,G,IT)
CN401 1-568-838-11 SOCKET, CONNECTOR 21P
* CN402 1-568-830-11 SOCKET, CONNECTOR 11P
* CN403 1-568-449-11 HOUSING,CONNECTOR(PC BOARD)3P
CN701 1-568-802-11 SOCKET, CONNECTOR 19P
(D670AV/N555AV:AEP,UK,G,IT)
* CN701 1-568-838-11 SOCKET, CONNECTOR 21P
(N555AV:E,AUS,PX,MX,AR)
* CN1101 1-770-734-11 CONNECTOR, BOARD TO BOARD 20P
CN1102 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
< DIODE >
D201 8-719-987-63 DIODE 1N4148M
D202 8-719-987-63 DIODE 1N4148M
D251 8-719-987-63 DIODE 1N4148M (N555AV:AEP,UK,G,IT)
D401 8-719-933-54 DIODE HZS9A2L
D701 8-719-987-63 DIODE 1N4148M
D702 8-719-987-63 DIODE 1N4148M
D703 8-719-987-63 DIODE 1N4148M
D704 8-719-987-63 DIODE 1N4148M
D705 8-719-987-63 DIODE 1N4148M
D706 8-719-200-82 DIODE 11ES2
D707 8-719-987-63 DIODE 1N4148M
D708 8-719-987-63 DIODE 1N4148M
D711 8-719-200-82 DIODE 11ES2
D901 8-719-987-63 DIODE 1N4148M
D902 8-719-987-63 DIODE 1N4148M
D1001 8-719-200-82 DIODE 11ES2
D1002 8-719-200-82 DIODE 11ES2
D1003 8-719-028-23 DIODE D3SBA20-4101
D1007 8-719-987-63 DIODE 1N4148M
D1008 8-719-001-43 DIODE UZL-11M1-TA
D1009 8-719-987-63 DIODE 1N4148M
D1010 8-719-987-63 DIODE 1N4148M
D1011 8-719-010-43 DIODE UZ-5.6BSC
D1012 8-719-934-22 DIODE HZS30-2L
D1013 8-719-200-82 DIODE 11ES2
D1014 8-719-200-82 DIODE 11ES2
D1015 8-719-200-82 DIODE 11ES2
D1016 8-719-200-82 DIODE 11ES2
D1017 8-719-200-82 DIODE 11ES2
D1018 8-719-200-82 DIODE 11ES2
D1019 8-719-200-82 DIODE 11ES2
< GROUND TERMINAL >
EPT902 1-537-770-21 TERMINAL BOARD, GROUND
< IC >
IC250 8-759-169-99 IC SAA6579 (N555AV:AEP,UK,G,IT)
IC251 8-759-634-51 IC M5218AP (N555AV:AEP,UK,G,IT)
IC401 8-759-289-38 IC HA12195NT (D670AV/N555AV:AEP,UK,G,IT)
IC401 8-759-289-39 IC HA12196NT (N555AV:E,AUS,PX,MX,AR)
IC402 8-759-822-09 IC LB1641
IC701 8-759-392-42 IC TMP87CS64YF-6397
IC702 8-759-165-80 IC PST600C-T
IC801 8-759-634-51 IC M5218AP
IC802 8-759-000-48 IC MC14052BCP
IC803 8-759-140-53 IC UPD4053BC
IC805 8-759-634-51 IC M5218AP
IC901 8-759-331-39 IC M62427FP
IC902 8-759-634-51 IC M5218AP
IC1001 8-759-231-53 IC TA7805S
IC1002 8-759-604-86 IC M5F7807L
IC1003 8-759-604-86 IC M5F7807L
IC1004 8-759-604-90 IC M5F7907L
IC1101 8-759-248-74 IC LA2785
IC1102 8-759-341-23 IC LV1011
IC1103 8-759-634-51 IC M5218AP
IC1104 8-759-281-42 IC TC9210P
< JACK >
J801 1-695-188-31 JACK, PIN 4P (PHONO, VIDEO (AUDIO) IN)
MAIN
