— 101 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< COIL >
L250 1-410-521-11 INDUCTOR 100uH (N555AV:AEP,UK,G,IT)
L701 1-410-509-11 INDUCTOR 10uH
L702 1-410-509-11 INDUCTOR 10uH
L703 1-410-509-11 INDUCTOR 10uH
L704 1-410-509-11 INDUCTOR 10uH
L1101 1-410-509-11 INDUCTOR 10uH
L1102 1-410-509-11 INDUCTOR 10uH
L1104 1-410-509-11 INDUCTOR 10uH
< TRANSISTOR >
Q301 8-729-119-78 TRANSISTOR 2SC403SP-51
Q351 8-729-119-78 TRANSISTOR 2SC403SP-51
Q401 8-729-119-78 TRANSISTOR 2SC403SP-51
Q402 8-729-900-65 TRANSISTOR DTA144ES
Q403 8-729-801-93 TRANSISTOR 2SD1387
Q406 8-729-900-80 TRANSISTOR DTC114ES
Q407 8-729-422-57 TRANSISTOR UN4111
Q408 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q409 8-729-900-80 TRANSISTOR DTC114ES
Q410 8-729-900-65 TRANSISTOR DTA144ES
Q411 8-729-900-65 TRANSISTOR DTA144ES
Q412 8-729-900-65 TRANSISTOR DTA144ES
Q701 8-729-119-78 TRANSISTOR 2SC403SP-51
Q820 8-729-422-57 TRANSISTOR UN4111
Q821 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q822 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q823 8-729-422-57 TRANSISTOR UN4111
Q824 8-729-900-80 TRANSISTOR DTC114ES
Q830 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q901 8-729-119-78 TRANSISTOR 2SC403SP-51
Q902 8-729-119-78 TRANSISTOR 2SC403SP-51
Q951 8-729-119-78 TRANSISTOR 2SC403SP-51
Q952 8-729-119-78 TRANSISTOR 2SC403SP-51
Q953 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q954 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q1001 8-729-118-01 TRANSISTOR 2SB1116
Q1002 8-729-900-36 TRANSISTOR DTC124ES
Q1003 8-729-021-82 TRANSISTOR 2SD2396K
Q1006 8-729-118-01 TRANSISTOR 2SB1116
Q1101 8-729-141-26 TRANSISTOR 2SC3622A-LK
Q1102 8-729-141-26 TRANSISTOR 2SC3622A-LK
< RESISTOR >
R201 1-249-415-11 CARBON 680 5% 1/4W F
R202 1-249-435-11 CARBON 33K 5% 1/4W
R211 1-249-415-11 CARBON 680 5% 1/4W F
R212 1-249-435-11 CARBON 33K 5% 1/4W
R250 1-249-421-11 CARBON 2.2K 5% 1/4W F
(N555AV:AEP,UK,G,IT)
R251 1-249-401-11 CARBON 47 5% 1/4W F
(N555AV:AEP,UK,G,IT)
R252 1-249-441-11 CARBON 100K 5% 1/4W
(N555AV:AEP,UK,G,IT)
R253 1-249-441-11 CARBON 100K 5% 1/4W
(N555AV:AEP,UK,G,IT)
R254 1-249-426-11 CARBON 5.6K 5% 1/4W
(N555AV:AEP,UK,G,IT)
R255 1-249-429-11 CARBON 10K 5% 1/4W
(N555AV:AEP,UK,G,IT)
R256 1-247-807-31 CARBON 100 5% 1/4W
(N555AV:AEP,UK,G,IT)
R301 1-249-430-11 CARBON 12K 5% 1/4W
R302 1-249-431-11 CARBON 15K 5% 1/4W
R303 1-249-432-11 CARBON 18K 5% 1/4W
(D670AV/N555AV:AEP,UK,G,IT)
R304 1-249-428-11 CARBON 8.2K 5% 1/4W F
R305 1-249-425-11 CARBON 4.7K 5% 1/4W F
R306 1-247-840-00 CARBON 2.4K 5% 1/4W
R307 1-247-863-91 CARBON 22K 5% 1/4W
R308 1-249-421-11 CARBON 2.2K 5% 1/4W F
R309 1-249-428-11 CARBON 8.2K 5% 1/4W F
R310 1-249-417-11 CARBON 1K 5% 1/4W F
R351 1-249-430-11 CARBON 12K 5% 1/4W
R352 1-249-431-11 CARBON 15K 5% 1/4W
R354 1-249-428-11 CARBON 8.2K 5% 1/4W F
R355 1-249-425-11 CARBON 4.7K 5% 1/4W F
R356 1-247-840-00 CARBON 2.4K 5% 1/4W
R357 1-247-863-91 CARBON 22K 5% 1/4W
R358 1-249-421-11 CARBON 2.2K 5% 1/4W F
R359 1-249-428-11 CARBON 8.2K 5% 1/4W F
R360 1-249-417-11 CARBON 1K 5% 1/4W F
R401 1-249-425-11 CARBON 4.7K 5% 1/4W F
R402 1-249-425-11 CARBON 4.7K 5% 1/4W F
R403 1-249-425-11 CARBON 4.7K 5% 1/4W F
R404 1-249-417-11 CARBON 1K 5% 1/4W F
R405 1-249-437-11 CARBON 47K 5% 1/4W
R406 1-249-437-11 CARBON 47K 5% 1/4W
R407 1-249-437-11 CARBON 47K 5% 1/4W
R408 1-249-437-11 CARBON 47K 5% 1/4W
R409 1-249-429-11 CARBON 10K 5% 1/4W
R410 1-247-882-11 CARBON 130K 5% 1/4W
R411 1-247-866-11 CARBON 30K 5% 1/4W
R412 1-249-429-11 CARBON 10K 5% 1/4W
(D670AV/N555AV:AEP,UK,G,IT)
R413 1-247-864-11 CARBON 24K 5% 1/4W
R414 1-249-429-11 CARBON 10K 5% 1/4W
R415 1-249-429-11 CARBON 10K 5% 1/4W
R416 1-249-429-11 CARBON 10K 5% 1/4W
R417 1-249-429-11 CARBON 10K 5% 1/4W
R418 1-249-429-11 CARBON 10K 5% 1/4W
R419 1-249-429-11 CARBON 10K 5% 1/4W
MAIN
