— 104 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C433 1-162-209-31 CERAMIC 27PF 5% 50V
C601 1-126-157-11 ELECT 10uF 20% 16V
C602 1-126-157-11 ELECT 10uF 20% 16V
C611 1-124-907-11 ELECT 10uF 20% 50V
C612 1-124-907-11 ELECT 10uF 20% 50V
C621 1-137-150-11 FILM 0.01uF 5% 100V
C622 1-126-961-11 ELECT 2.2uF 20% 50V
C623 1-136-155-00 FILM 0.015uF 5% 50V
C624 1-130-481-00 MYLAR 0.0068uF 5% 50V
C625 1-130-481-00 MYLAR 0.0068uF 5% 50V
C627 1-124-903-11 ELECT 1uF 20% 50V
C628 1-136-153-00 FILM 0.01uF 5% 50V
C642 1-104-664-11 ELECT 47uF 20% 16V
C651 1-161-494-00 CERAMIC 0.022uF 25V
< CONNECTOR >
* CN601 1-568-864-11 SOCKET, CONNECTOR 21P
* CN602 1-564-718-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN651 1-564-521-11 PLUG, CONNECTOR 6P
< IC >
IC601 8-759-710-59 IC NJM4580D-D
IC602 8-759-143-54 IC uPC1330HA
IC611 8-759-710-59 IC NJM4580D-D
< COIL >
L331 1-410-780-11 INDUCTOR 27mH
L431 1-410-780-11 INDUCTOR 27mH
< MOTOR >
M2 X-3369-111-1 MOTOR ASSY (TRIGGER)
< TRANSISTOR >
Q621 8-729-142-46 TRANSISTOR 2SC2001-LK
Q622 8-729-142-46 TRANSISTOR 2SC2001-LK
Q623 8-729-030-18 TRANSISTOR 2SD2525
Q651 8-729-900-65 TRANSISTOR DTA144ES
< RESISTOR >
R301 1-247-881-00 CARBON 120K 5% 1/4W
R302 1-249-409-11 CARBON 220 5% 1/4W F
R303 1-249-433-11 CARBON 22K 5% 1/4W
R304 1-247-889-00 CARBON 270K 5% 1/4W
R305 1-247-858-11 CARBON 13K 5% 1/4W
R311 1-247-881-00 CARBON 120K 5% 1/4W
R312 1-247-807-31 CARBON 100 5% 1/4W
R314 1-247-882-11 CARBON 130K 5% 1/4W
R315 1-247-850-11 CARBON 6.2K 5% 1/4W
R331 1-249-430-11 CARBON 12K 5% 1/4W
R401 1-247-881-00 CARBON 120K 5% 1/4W
R1141 1-249-417-11 CARBON 1K 5% 1/4W F
R1142 1-249-417-11 CARBON 1K 5% 1/4W F
R1143 1-249-417-11 CARBON 1K 5% 1/4W F
R1144 1-249-417-11 CARBON 1K 5% 1/4W F
R1145 1-249-429-11 CARBON 10K 5% 1/4W
R1146 1-249-429-11 CARBON 10K 5% 1/4W
R1150 1-249-441-11 CARBON 100K 5% 1/4W
R1151 1-249-417-11 CARBON 1K 5% 1/4W F
< VARIABLE RESISTOR >
RV301 1-238-600-11 RES, ADJ, CARBON 10K
RV351 1-238-600-11 RES, ADJ, CARBON 10K
< VIBRATOR >
X81 1-579-900-21 VIBRATOR, CRYSTAL (4,332MHz)
(N555AV:AEP,UK,G,IT)
X701 1-579-175-11 VIBRATOR, CERAMIC (10MHz)
X702 1-567-098-41 VIBRATOR, CRYSTAL (32kHz)
X1101 1-579-125-11 VIBRATOR, CERAMIC (320kHz)
**************************************************************
* A-2007-435-A MD BOARD, COMPLETE
******************
(including MOTOR board)
MOTOR BOARD
< CAPACITOR >
C301 1-162-289-31 CERAMIC 390PF 10% 50V
C302 1-126-968-11 ELECT 100uF 20% 6.3V
C303 1-162-282-31 CERAMIC 100PF 10% 50V
C304 1-130-483-00 MYLAR 0.01uF 5% 50V
C305 1-107-715-11 ELECT 22uF 20% 16V
C311 1-162-289-31 CERAMIC 390PF 10% 50V
C313 1-162-282-31 CERAMIC 100PF 10% 50V
C314 1-130-487-00 MYLAR 0.022uF 5% 50V
C315 1-126-233-11 ELECT 22uF 20% 50V
C331 1-137-427-11 FILM 120PF 5% 50V
C332 1-162-288-31 CERAMIC 330PF 10% 50V
C333 1-162-209-31 CERAMIC 27PF 5% 50V
C401 1-162-289-31 CERAMIC 390PF 10% 50V
C402 1-126-968-11 ELECT 100uF 20% 6.3V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
C404 1-130-483-00 MYLAR 0.01uF 5% 50V
C405 1-107-715-11 ELECT 22uF 20% 16V
C411 1-162-289-31 CERAMIC 390PF 10% 50V
C413 1-162-282-31 CERAMIC 100PF 10% 50V
C414 1-130-487-00 MYLAR 0.022uF 5% 50V
C415 1-126-233-11 ELECT 22uF 20% 50V
C431 1-137-427-11 FILM 120PF 5% 50V
C432 1-162-288-31 CERAMIC 330PF 10% 50V
MAIN
MD
