Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C911 1-126-963-11 ELECT 4.7uF 20% 50V
C931 1-126-964-11 ELECT 10uF 20% 50V
C941 1-126-964-11 ELECT 10uF 20% 50V
< IC >
IC901 8-759-634-51 IC M5218AP
< JACK >
J901 1-573-151-11 JACK, LARGE TYPE (MIC)
< RESISTOR >
R900 1-249-417-11 CARBON 1K 5% 1/4W F
R901 1-249-429-11 CARBON 10K 5% 1/4W
R902 1-249-417-11 CARBON 1K 5% 1/4W F
R903 1-249-441-11 CARBON 100K 5% 1/4W
R904 1-249-417-11 CARBON 1K 5% 1/4W F
R905 1-247-863-91 CARBON 22K 5% 1/4W
R906 1-247-839-11 CARBON 2.2K 5% 1/4W
R907 1-249-436-11 CARBON 39K 5% 1/4W F
R931 1-247-887-00 CARBON 220K 5% 1/4W
< VARIABLE RESISTOR >
RV901 1-223-983-11 RES, VAR, CARBON 50K (MIC LEVEL)
**************************************************************
* A-4389-610-A PANEL BOARD, COMPLETE (D670AV)
******************************
* A-4389-629-A PANEL BOARD, COMPLETE
*********************
(N555AV:AEP,UK,G,IT)
* A-4389-619-A PANEL BOARD, COMPLETE
*********************
(N555AV:E,AUS,PX,MX,AR)
4-971-014-11 HOLDER, FL TUBE
< CAPACITOR >
C501 1-126-160-11 ELECT 1uF 20% 50V
C502 1-164-159-21 CERAMIC 0.1uF 50V
C503 1-126-160-11 ELECT 1uF 20% 50V
C504 1-164-159-21 CERAMIC 0.1uF 50V
C505 1-162-294-31 CERAMIC 0.001uF 10% 50V
C506 1-124-584-00 ELECT 100uF 20% 10V
C511 1-164-159-21 CERAMIC 0.1uF 50V
C512 1-164-159-21 CERAMIC 0.1uF 50V
C513 1-164-159-21 CERAMIC 0.1uF 50V
C514 1-164-159-21 CERAMIC 0.1uF 50V
C515 1-126-793-11 ELECT 33uF 20% 35V
C518 1-126-157-11 ELECT 10uF 20% 16V
R402 1-249-409-11 CARBON 220 5% 1/4W F
R403 1-249-433-11 CARBON 22K 5% 1/4W
R404 1-247-889-00 CARBON 270K 5% 1/4W
R405 1-247-858-11 CARBON 13K 5% 1/4W
R411 1-247-881-00 CARBON 120K 5% 1/4W
R412 1-247-807-31 CARBON 100 5% 1/4W
R414 1-247-882-11 CARBON 130K 5% 1/4W
R415 1-247-850-11 CARBON 6.2K 5% 1/4W
R431 1-249-430-11 CARBON 12K 5% 1/4W
R601 1-249-409-11 CARBON 220 5% 1/4W F
R602 1-249-409-11 CARBON 220 5% 1/4W F
R608 1-249-409-11 CARBON 220 5% 1/4W F
R609 1-249-433-11 CARBON 22K 5% 1/4W
R611 1-249-409-11 CARBON 220 5% 1/4W F
R612 1-249-409-11 CARBON 220 5% 1/4W F
! R621 1-212-851-00 FUSIBLE 5.6 5% 1/4W F
! R622 1-212-851-00 FUSIBLE 5.6 5% 1/4W F
R623 1-249-432-11 CARBON 18K 5% 1/4W
R624 1-249-432-11 CARBON 18K 5% 1/4W
R625 1-249-429-11 CARBON 10K 5% 1/4W
R651 1-247-856-00 CARBON 11K 5% 1/4W
R652 1-247-856-00 CARBON 11K 5% 1/4W
R653 1-249-441-11 CARBON 100K 5% 1/4W
< VARIABLE RESISTOR >
RV301 1-238-598-11 RES, ADJ, CARBON 2.2K
RV311 1-238-598-11 RES, ADJ, CARBON 2.2K
RV341 1-238-551-11 RES, ADJ, CARBON 220K
RV401 1-238-598-11 RES, ADJ, CARBON 2.2K
RV411 1-238-598-11 RES, ADJ, CARBON 2.2K
RV441 1-238-551-11 RES, ADJ, CARBON 220K
RV651 1-238-599-11 RES, ADJ, CARBON 4.7K
RV652 1-238-599-11 RES, ADJ, CARBON 4.7K
< TRANSFORMER >
T621 1-423-980-11 TRANSFORMER, BIAS OSCILLATION
**************************************************************
* 1-659-414-11 MIC BOARD (N555AV:E,AUS,PX,MX,AR)
*********************************
< CAPACITOR >
C901 1-162-306-11 CERAMIC 0.01uF 30% 16V
C903 1-162-294-31 CERAMIC 0.001uF 10% 50V
C904 1-124-257-00 ELECT 2.2uF 20% 50V
C905 1-162-215-31 CERAMIC 47PF 5% 50V
C906 1-162-290-31 CERAMIC 470PF 10% 50V
C907 1-136-160-00 FILM 0.039uF 5% 50V
C908 1-124-257-00 ELECT 2.2uF 20% 50V
C909 1-162-215-31 CERAMIC 47PF 5% 50V
C910 1-162-286-21 CERAMIC 220PF 10% 50V
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
