— 108 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S528 1-554-303-21 SWITCH, TACTILE (FILE 2)
S529 1-554-303-21 SWITCH, TACTILE (FILE 3)
S530 1-554-303-21 SWITCH, TACTILE (FILE 4)
S531 1-554-303-21 SWITCH, TACTILE (FILE SELECT)
S532 1-554-303-21 SWITCH, TACTILE (FILE 5)
S549 1-554-303-21 SWITCH, TACTILE (SUPER WOOFER)(N555AV)
S551 1-554-303-21 SWITCH, TACTILE (DBFB)
S552 1-554-303-21 SWITCH, TACTILE (TUNER/BAND)
S553 1-554-303-21 SWITCH, TACTILE (PTY)(N555AV:AEP,UK,G,IT)
S565 1-554-303-21 SWITCH, TACTILE (STEREO/MONO)
S566 1-554-303-21 SWITCH, TACTILE (TUNER MEMORY)
S567 1-554-303-21 SWITCH, TACTILE (+ TUNING)
S568 1-554-303-21 SWITCH, TACTILE (- TUNING)
S579 1-467-869-11 ENCODER, ROTARY (VOLUME)
< VIBRATOR >
X3001 1-579-233-11 VIBRATOR, CERAMIC (4MHz)
**************************************************************
* A-4389-604-A POWER AMP BOARD, COMPLETE (D670AV)
***********************************
* A-4389-617-A POWER AMP BOARD, COMPLETE
****************************
(N555AV:E,AUS,PX,MX,AR)
* A-4389-625-A POWER AMP BOARD, COMPLETE
*************************************
(N555AV:AEP,UK,G,IT)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C1201 1-126-963-11 ELECT 4.7uF 20% 50V
C1202 1-162-294-31 CERAMIC 1000PF 10% 50V
C1203 1-162-286-21 CERAMIC 220PF 10% 50V
C1204 1-126-967-11 ELECT 47uF 20% 50V
C1205 1-126-967-11 ELECT 47uF 20% 50V
C1206 1-126-968-11 ELECT 100uF 20% 50V
C1207 1-162-306-11 CERAMIC 0.01uF 5% 50V
C1208 1-126-965-11 ELECT 22uF 20% 50V
C1209 1-162-306-11 CERAMIC 0.01uF 5% 50V
C1210 1-136-495-11 FILM 0.068uF 5% 50V
C1211 1-136-495-11 FILM 0.068uF 5% 50V
C1212 1-126-964-11 ELECT 10uF 20% 50V
C1220 1-126-933-11 ELECT 100uF 20% 10V
C1226 1-161-494-00 CERAMIC 0.022uF 30% 50V
(N555AV:AEP,UK,G,IT)
C1231 1-126-923-11 ELECT 220uF 20% 10V
C1232 1-126-923-11 ELECT 220uF 20% 10V
C1233 1-124-925-11 ELECT 2.2uF 20% 100V
C1234 1-126-933-11 ELECT 100uF 20% 10V
R3087 1-249-441-11 CARBON 100K 5% 1/4W
R3110 1-247-807-31 CARBON 100 5% 1/4W
R3115 1-247-807-31 CARBON 100 5% 1/4W
R3122 1-247-807-31 CARBON 100 5% 1/4W
R3123 1-247-807-31 CARBON 100 5% 1/4W
R3124 1-247-807-31 CARBON 100 5% 1/4W
R3138 1-247-807-31 CARBON 100 5% 1/4W
R3201 1-249-411-11 CARBON 330 5% 1/4W
R3202 1-249-437-11 CARBON 47K 5% 1/4W
R3203 1-247-895-91 CARBON 470K 5% 1/4W
R3204 1-247-899-11 CARBON 680K 5% 1/4W
R3211 1-249-411-11 CARBON 330 5% 1/4W
R3212 1-249-437-11 CARBON 47K 5% 1/4W
R3213 1-247-895-91 CARBON 470K 5% 1/4W
R3214 1-247-899-11 CARBON 680K 5% 1/4W
R3221 1-249-411-11 CARBON 330 5% 1/4W
R3222 1-249-437-11 CARBON 47K 5% 1/4W
R3223 1-247-895-91 CARBON 470K 5% 1/4W
R3224 1-247-899-11 CARBON 680K 5% 1/4W
R3231 1-247-807-31 CARBON 100 5% 1/4W
R3232 1-249-437-11 CARBON 47K 5% 1/4W
R3233 1-247-895-91 CARBON 470K 5% 1/4W
R3234 1-247-899-11 CARBON 680K 5% 1/4W
R3241 1-249-421-11 CARBON 2.2K 5% 1/4W F
R3242 1-249-393-11 CARBON 10 5% 1/4W F
< SWITCH >
S501 1-554-303-21 SWITCH, TACTILE (SYSTEM POWER)
S502 1-554-303-21 SWITCH, TACTILE (SLEEP)
S503 1-554-303-21 SWITCH, TACTILE (CLOCK SET)
S504 1-554-303-21 SWITCH, TACTILE (EFFECT)
S506 1-554-303-21 SWITCH, TACTILE (KARAOKEPON/MPX)
(N555AV:E,AUS,PX,MX,AR)
S507 1-554-303-21 SWITCH, TACTILE (TUNING MODE)
S508 1-554-303-21 SWITCH, TACTILE (>)
S509 1-554-303-21 SWITCH, TACTILE ( )
S510 1-554-303-21 SWITCH, TACTILE (<)
S511 1-554-303-21 SWITCH, TACTILE ( )
S512 1-554-303-21 SWITCH, TACTILE (LIVE)
S513 1-554-303-21 SWITCH, TACTILE (THEATER)
S514 1-554-303-21 SWITCH, TACTILE (HALL)
S515 1-554-303-21 SWITCH, TACTILE (ON/OFF, DOLBY SURROUND)
S516 1-554-303-21 SWITCH, TACTILE (CENTER MODE, SURROUND)
S517 1-554-303-21 SWITCH, TACTILE (ENTER/NEXT)
S518 1-554-303-21 SWITCH, TACTILE (DISPLAY/DEMO)
S519 1-554-303-21 SWITCH, TACTILE (REC)
S520 1-554-303-21 SWITCH, TACTILE (DAILY 2)
S521 1-554-303-21 SWITCH, TACTILE (DAILY 1)
S522 1-554-303-21 SWITCH, TACTILE (TIMER SET)
S525 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S526 1-554-303-21 SWITCH, TACTILE (EQ MEMORY)
S527 1-554-303-21 SWITCH, TACTILE (FILE 1)
PANEL
POWER AMP
>
>
To Next Page
