Sony HCD-D670AV - Compact Disk Deck Receiver - Power Amplifier Section Parts List

— 109 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C1247 1-161-494-00 CERAMIC 0.022uF 30% 50V
(N555AV:AEP,UK,G,IT)
C1248 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1249 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1251 1-126-963-11 ELECT 4.7uF 20% 50V
C1252 1-162-294-31 CERAMIC 1000PF 10% 50V
C1253 1-162-286-21 CERAMIC 220PF 10% 50V
C1254 1-126-967-11 ELECT 47uF 20% 50V
C1255 1-126-967-11 ELECT 47uF 20% 50V
C1256 1-126-968-11 ELECT 100uF 20% 50V
C1260 1-136-495-11 FILM 0.068uF 5% 50V
C1261 1-136-495-11 FILM 0.068uF 5% 50V
C1270 1-130-781-00 FILM 0.22uF 10% 100V
C1271 1-130-781-00 FILM 0.22uF 10% 100V
C1272 1-126-138-11 ELECT 4700uF 20% 50V
(D670AV/N555AV:AEP,UK,G,IT)
C1272 1-128-493-11 ELECT 4700uF 20% 71V
(N555AV: E,AUS,MX,PX,AR)
C1273 1-126-138-11 ELECT 4700uF 20% 50V
(D670AV/N555AV:AEP,UK,G,IT)
C1273 1-128-493-11 ELECT 4700uF 20% 71V
(N555AV: E,AUS,MX,PX,AR)
C1297 1-161-494-00 CERAMIC 0.022uF 30% 50V
(N555AV:AEP,UK,G,IT)
C1298 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1299 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1301 1-126-963-11 ELECT 4.7uF 20% 50V
C1302 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1303 1-162-286-21 CERAMIC 220PF 10% 50V
C1304 1-126-967-11 ELECT 47uF 20% 50V
C1305 1-126-967-11 ELECT 47uF 20% 50V
C1306 1-126-968-11 ELECT 100uF 20% 50V
C1308 1-126-965-11 ELECT 22uF 20% 50V
C1310 1-136-495-11 FILM 0.068uF 5% 50V
C1311 1-136-495-11 FILM 0.068uF 5% 50V
C1326 1-161-494-00 CERAMIC 0.022uF 30% 50V
(N555AV:AEP,UK,G,IT)
C1347 1-161-494-00 CERAMIC 0.022uF 30% 50V
(N555AV:AEP,UK,G,IT)
C1348 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1349 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1351 1-126-963-11 ELECT 4.7uF 20% 50V
C1352 1-162-294-31 CERAMIC 0.001uF 10% 50V
C1353 1-162-286-21 CERAMIC 220PF 10% 50V
C1354 1-126-967-11 ELECT 47uF 20% 50V
C1355 1-126-967-11 ELECT 47uF 20% 50V
C1356 1-126-968-11 ELECT 100uF 20% 50V
C1360 1-136-495-11 FILM 0.068uF 5% 50V
C1361 1-136-495-11 FILM 0.068uF 5% 50V
C1397 1-136-157-00 FILM 0.022uF 5% 50V
(N555AV:AEP,UK,G,IT)
C1398 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1399 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1431 1-124-902-00 ELECT 0.47uF 20% 50V
C1447 1-161-494-00 CERAMIC 0.022uF 30% 50V
(N555AV:AEP,UK,G,IT)
C1448 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1449 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1481 1-162-294-31 CERAMIC 0.001uF 10% 50V
(N555AV)
C1482 1-137-399-11 FILM 0.1uF 5% 50V
(N555AV)
C1483 1-137-399-11 FILM 0.1uF 5% 50V
(N555AV)
C1484 1-136-167-00 FILM 0.15uF 5% 50V
(N555AV)
C1485 1-136-171-00 FILM 0.33uF 5% 50V
(N555AV)
C1486 1-136-155-00 FILM 0.015uF 5% 50V
(N555AV)
C1489 1-126-964-11 ELECT 10uF 20% 50V
(N555AV)
C1492 1-126-964-11 ELECT 10uF 20% 50V
(N555AV)
C1493 1-126-964-11 ELECT 10uF 20% 50V
(N555AV)
C1497 1-161-494-00 CERAMIC 0.022uF 30% 50V
(N555AV:AEP,UK,G,IT)
C1498 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
C1499 1-164-159-21 CERAMIC 0.1uF 50V
(N555AV:AEP,UK,G,IT)
< CONNECTOR >
* CN1201 1-766-957-11 CONNECTOR, BOARD TO BOARD 20P
CN1301 1-564-506-11 PLUG, CONNECTOR 3P (D670AV)
* CN1301 1-564-508-11 PLUG, CONNECTOR 5P (N555AV)
* CN1401 1-564-509-11 PLUG, CONNECTOR 6P (N555AV)
CN1404 1-564-510-11 PLUG, CONNECTOR 7P (N555AV)
< DIODE >
D1201 8-719-987-63 DIODE 1N4148M
D1202 8-719-987-63 DIODE 1N4148M
D1204 8-719-987-63 DIODE 1N4148M
D1206 8-719-987-63 DIODE 1N4148M
D1207 8-719-987-63 DIODE 1N4148M
D1209 8-719-987-63 DIODE 1N4148M
POWER AMP
