— 110 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
D1210 8-719-987-63 DIODE 1N4148M
D1211 8-719-987-63 DIODE 1N4148M
D1212 8-719-987-63 DIODE 1N4148M
D1213 8-719-987-63 DIODE 1N4148M
D1231 8-719-987-63 DIODE 1N4148M
D1232 8-719-987-63 DIODE 1N4148M
D1240 8-719-987-63 DIODE 1N4148M
D1250 8-719-302-38 DIODE RBV-602-01
D1251 8-719-987-63 DIODE 1N4148M
D1301 8-719-987-63 DIODE 1N4148M
D1304 8-719-987-63 DIODE 1N4148M
D1306 8-719-987-63 DIODE 1N4148M
D1307 8-719-987-63 DIODE 1N4148M
D1308 8-719-987-63 DIODE 1N4148M
D1341 8-719-987-63 DIODE 1N4148M
D1351 8-719-987-63 DIODE 1N4148M
D1406 8-719-987-63 DIODE 1N4148M (N555AV)
D1407 8-719-987-63 DIODE 1N4148M (N555AV)
D1408 8-719-987-63 DIODE 1N4148M (N555AV)
D1411 8-719-987-63 DIODE 1N4148M (N555AV)
D1412 8-719-987-63 DIODE 1N4148M (N555AV)
D1431 8-719-987-63 DIODE 1N4148M
D1441 8-719-987-63 DIODE 1N4148M (N555AV)
<GROUND TERMINAL>
* EPT1201 1-537-738-21 GROUND, TERMINAL
< IC >
IC1201 8-749-900-24 IC STK-4162MK2 (N555AV:AEP,UK,G,IT)
IC1201 8-749-900-34 IC STK-4182MK2 (D670AV)
IC1201 8-749-941-52 IC STK-4152II (N555AV:E,AUS,PX,MX,AR)
IC1202 8-759-111-68 IC UPC1237HA
IC1301 8-749-900-24 IC STK-4162MK2 (N555AV:AEP,UK,G,IT)
IC1301 8-749-900-34 IC STK-4182MK2 (D670AV)
IC1301 8-749-941-52 IC STK-4152II (N555AV:E,AUS,PX,MX,AR)
IC1402 8-759-634-51 IC M5218AP (N555AV)
IC1403 8-759-634-51 IC M5218AP (N555AV)
< COIL >
L1201 1-420-872-00 COIL, AIR-CORE (N555AV:AEP,UK,G,IT)
L1251 1-420-872-00 COIL, AIR-CORE (N555AV:AEP,UK,G,IT)
L1301 1-420-872-00 COIL, AIR-CORE (N555AV:AEP,UK,G,IT)
L1351 1-420-872-00 COIL, AIR-CORE (N555AV:AEP,UK,G,IT)
L1401 1-420-872-00 COIL, AIR-CORE (N555AV:AEP,UK,G,IT)
L1451 1-420-872-00 COIL, AIR-CORE (N555AV:AEP,UK,G,IT)
< TRANSISTOR >
Q1201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1206 8-729-422-57 TRANSISTOR UN4111
Q1207 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1208 8-729-900-80 TRANSISTOR DTC114ES
Q1230 8-729-119-78 TRANSISTOR 2SC403SP-51
Q1240 8-729-900-63 TRANSISTOR DTA124ES
Q1251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1301 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1307 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1351 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q1404 8-729-141-26 TRANSISTOR 2SC3622A-LK (N555AV)
Q1405 8-729-141-26 TRANSISTOR 2SC3622A-LK (N555AV)
Q1407 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA (N555AV)
< RESISTOR >
R1201 1-249-417-11 CARBON 1K 5% 1/4W F
R1202 1-249-437-11 CARBON 47K 5% 1/4W
R1203 1-249-415-11 CARBON 680 5% 1/4W F
R1204 1-249-437-11 CARBON 47K 5% 1/4W
R1205 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1206 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1207 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1208 1-249-425-11 CARBON 4.7K 5% 1/4W F
! R1209 1-212-881-11 FUSIBLE 100 5% 1/4W F
! R1210 1-208-602-11 WIREWOUND 0.22 10% 2W F
R1211 1-249-417-11 CARBON 1K 5% 1/4W F
R1212 1-249-431-11 CARBON 15K 5% 1/4W
R1213 1-249-441-11 CARBON 100K 5% 1/4W
R1214 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1215 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1216 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1217 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1218 1-247-791-91 CARBON 22 5% 1/4W
R1219 1-247-791-91 CARBON 22 5% 1/4W
R1220 1-249-389-11 CARBON 4.7 5% 1/4W F
(N555AV:AEP,UK,G,IT)
R1221 1-249-389-11 CARBON 4.7 5% 1/4W F
(N555AV:AEP,UK,G,IT)
R1222 1-249-413-11 CARBON 470 5% 1/4W F
R1223 1-249-429-11 CARBON 10K 5% 1/4W
R1224 1-249-429-11 CARBON 10K 5% 1/4W
R1225 1-249-417-11 CARBON 1K 5% 1/4W F
R1226 1-249-421-11 CARBON 2.2K 5% 1/4W F
R1227 1-249-429-11 CARBON 10K 5% 1/4W
R1228 1-249-441-11 CARBON 100K 5% 1/4W
R1229 1-249-429-11 CARBON 10K 5% 1/4W
R1231 1-249-429-11 CARBON 10K 5% 1/4W
R1232 1-249-441-11 CARBON 100K 5% 1/4W
R1233 1-249-435-11 CARBON 33K 5% 1/4W
R1234 1-247-791-91 CARBON 22 5% 1/4W
R1235 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1236 1-249-425-11 CARBON 4.7K 5% 1/4W F
R1237 1-249-438-11 CARBON 56K 5% 1/4W
R1238 1-249-437-11 CARBON 47K 5% 1/4W
R1239 1-247-863-91 CARBON 22K 5% 1/4W
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
POWER AMP
