Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< RESISTOR >
R533 1-249-419-11 CARBON 1.5K 5% 1/4W F
R534 1-249-421-11 CARBON 2.2K 5% 1/4W F
R535 1-249-423-11 CARBON 3.3K 5% 1/4W F
R536 1-249-427-11 CARBON 6.8K 5% 1/4W F
R537 1-249-431-11 CARBON 15K 5% 1/4W
(D670AV/N555QV:AEP,UK,G,IT)
R590 1-249-417-11 CARBON 1K 5% 1/4W F
< SWITCH >
S533 1-554-303-21 SWITCH, TACTILE (CD SYNCHRO)
S534 1-554-303-21 SWITCH, TACTILE (HIGH SPEED DUBBING)
S535 1-554-303-21 SWITCH, TACTILE (P)
S536 1-554-303-21 SWITCH, TACTILE (rREC)
S537 1-554-303-21 SWITCH, TACTILE (DIRECTION)
S538 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
(D670AV/N555AV:AEP,UK,G,IT)
**************************************************************
*
A-4303-510-A TCB BOARD, COMPLETE (D670AV)
****************************
* A-4303-513-A TCB BOARD,COMPLETE
******************
(N555AV:E,AUS,AR,MX,PX)
< CAPACITOR >
C1 1-162-294-31 CERAMIC 0.001uF 10% 50V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-164-159-21 CERAMIC 0.1uF 50V
C5 1-162-306-11 CERAMIC 10000PF 30% 16V
C6 1-162-306-11 CERAMIC 10000PF 30% 16V
C7 1-101-004-00 CERAMIC 0.01uF 50V
C8 1-162-306-11 CERAMIC 10000PF 30% 16V
C9 1-162-306-11 CERAMIC 10000PF 30% 16V
C11 1-164-159-21 CERAMIC 0.1uF 50V
C12 1-162-198-31 CERAMIC 8.2PF 10% 50V
C14 1-162-306-11 CERAMIC 10000PF 30% 16V
C21 1-102-959-00 CERAMIC 22PF 5% 50V
C22 1-164-159-21 CERAMIC 0.1uF 50V
C23 1-162-306-11 CERAMIC 10000PF 30% 16V
C24 1-126-967-11 ELECT 47uF 20% 16V
C25 1-162-306-11 CERAMIC 10000PF 30% 16V
C26 1-126-964-11 ELECT 10uF 20% 50V
C27 1-164-159-21 CERAMIC 0.1uF 50V
C28 1-124-925-11 ELECT 2.2uF 20% 100V
C29 1-102-518-11 CERAMIC 33PF 5% 50V
C30 1-162-294-31 CERAMIC 0.001uF 10% 50V
C31 1-162-306-11 CERAMIC 10000PF 30% 16V
C41 1-126-933-11 ELECT 100uF 20% 10V
C43 1-126-962-11 ELECT 3.3uF 20% 50V
C44 1-162-306-11 CERAMIC 10000PF 30% 16V
C45 1-124-589-11 ELECT 47uF 20% 16V
C46 1-162-600-11 CERAMIC 4700PF 30% 16V
C47 1-162-294-31 CERAMIC 0.001uF 10% 50V
C48 1-126-160-11 ELECT 1uF 20% 50V
C49 1-136-159-00 METALIZED FILM 0.033uF 5% 50V
(N555AV:E,AUS,AR,MX,PX)
C49 1-136-160-00 METALIZED FILM 0.039uF 5% 50V
(D670AV)
C50 1-136-159-00 METALIZED FILM 0.033uF 5% 50V
(N555AV:E,AUS,AR,MX,PX)
C50 1-136-160-00 METALIZED FILM 0.039uF 5% 50V
(D670AV)
C51 1-162-600-11 CERAMIC 4700PF 30% 16V
(D670AV)
C52 1-162-600-11 CERAMIC 4700PF 30% 16V
(D670AV)
C53 1-126-964-11 ELECT 10uF 20% 50V
C54 1-126-157-11 ELECT 10uF 20% 16V
C55 1-126-964-11 ELECT 10uF 20% 50V
C56 1-126-964-11 ELECT 10uF 20% 50V
C57 1-164-159-21 CERAMIC 0.1uF 50V F
C58 1-162-306-11 CERAMIC 10000PF 30% 16V
C59 1-164-159-21 CERAMIC 0.1uF 50V F
C61 1-164-159-21 CERAMIC 0.1uF 50V F
C62 1-126-967-11 ELECT 47uF 20% 16V
C63 1-164-159-21 CERAMIC 0.1uF 50V F
C64 1-124-902-00 ELECT 0.47uF 20% 50V
C65 1-124-903-11 ELECT 1.0uF 20% 50V
C66 1-124-903-11 ELECT 1.0uF 20% 50V
C67 1-126-964-11 ELECT 10uF 20% 50V
C68 1-162-306-11 CERAMIC 10000PF 30% 16V
C69 1-162-306-11 CERAMIC 10000PF 30% 16V
C70 1-162-306-11 CERAMIC 10000PF 30% 16V
C71 1-162-306-11 CERAMIC 10000PF 30% 16V
C73 1-162-306-11 CERAMIC 10000PF 30% 16V
C74 1-126-964-11 ELECT 10uF 20% 50V
< FILTER >
CF1 1-567-389-11 FILTER, CERAMIC
CF2 1-567-389-11 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-832-11 SOCKET, CONNECTOR 13P
< DIODE >
D1 8-719-933-33 DIODE HZS6A1L
D2 8-719-987-63 DIODE 1N4148M
TC SW
TCB
