— 115 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
< FRONTEND >
FE1 1-233-533-11 ENCAPSULATED COMPONENT
FE2 1-239-260-11 ENCAPSULATED COMPONENT
< IC >
IC1 8-759-288-54 IC LC72130
IC2 8-759-176-03 IC LA1835
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< COIL >
L41 1-410-119-11 MICRO INDUCTOR (EL TYPE) 1mH
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS (D670AV)
LPF42 1-239-845-11 FILTER, LOW PASS (D670AV)
< TRANSISTOR >
Q1 8-729-230-99 TRANSISTOR 2SC2669-OY
Q2 8-729-230-99 TRANSISTOR 2SC2669-OY
Q3 8-729-230-99 TRANSISTOR 2SC2669-OY
Q4 8-729-230-99 TRANSISTOR 2SC2669-OY
Q5 8-729-422-57 TRANSISTOR UN4111
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W F
R2 1-249-411-11 CARBON 330 5% 1/4W
R3 1-249-411-11 CARBON 330 5% 1/4W
R5 1-249-411-11 CARBON 330 5% 1/4W
R6 1-247-863-91 CARBON 22K 5% 1/4W
R7 1-249-411-11 CARBON 330 5% 1/4W
R8 1-249-411-11 CARBON 330 5% 1/4W
R9 1-247-863-91 CARBON 22K 5% 1/4W
R10 1-249-411-11 CARBON 330 5% 1/4W
R11 1-247-863-91 CARBON 22K 5% 1/4W
R12 1-249-411-11 CARBON 330 5% 1/4W
R13 1-249-411-11 CARBON 330 5% 1/4W
R14 1-247-863-91 CARBON 22K 5% 1/4W
R15 1-249-429-11 CARBON 10K 5% 1/4W
R16 1-249-437-11 CARBON 47K 5% 1/4W
R19 1-249-399-11 CARBON 33 5% 1/4W F
R21 1-247-807-31 CARBON 100 5% 1/4W
R22 1-249-425-11 CARBON 4.7K 5% 1/4W F
R23 1-249-425-11 CARBON 4.7K 5% 1/4W F
R24 1-249-425-11 CARBON 4.7K 5% 1/4W F
R25 1-247-807-31 CARBON 100 5% 1/4W
R26 1-249-411-11 CARBON 330 5% 1/4W
R27 1-249-425-11 CARBON 4.7K 5% 1/4W F
R28 1-249-423-11 CARBON 3.3K 5% 1/4W F
R29 1-249-417-11 CARBON 1K 5% 1/4W F
R30 1-249-417-11 CARBON 1K 5% 1/4W F
R31 1-249-417-11 CARBON 1K 5% 1/4W F
R32 1-249-417-11 CARBON 1K 5% 1/4W F
R33 1-247-807-31 CARBON 100 5% 1/4W
R34 1-249-429-11 CARBON 10K 5% 1/4W
R35 1-249-429-11 CARBON 10K 5% 1/4W
R36 1-249-437-11 CARBON 47K 5% 1/4W
R37 1-249-417-11 CARBON 1K 5% 1/4W F
R41 1-249-429-11 CARBON 10K 5% 1/4W
R43 1-249-423-11 CARBON 3.3K 5% 1/4W F
R44 1-249-423-11 CARBON 3.3K 5% 1/4W F
R46 1-249-442-11 CARBON 510 5% 1/4W
R47 1-249-399-11 CARBON 33 5% 1/4W F
R48 1-249-423-11 CARBON 3.3K 5% 1/4W F
R49 1-249-393-11 CARBON 10 5% 1/4W F
R50 1-249-429-11 CARBON 10K 5% 1/4W
R51 1-249-441-11 CARBON 100K 5% 1/4W
R52 1-249-429-11 CARBON 10K 5% 1/4W
R53 1-249-425-11 CARBON 4.7K 5% 1/4W F
R54 1-249-425-11 CARBON 4.7K 5% 1/4W F
R99 1-249-399-11 CARBON 33 5% 1/4W F
< VARIABLE RESISTOR >
RV41 1-238-600-11 RES, ADJ, CARBON 10K
RV42 1-238-601-11 RES, ADJ, CARBON 22K
< TERMINAL >
TM1 1-537-238-21 TERMINAL BOARD (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-577-075-11 OSCILLATOR, CERAMIC (456KHz)
X42 1-760-220-11 FILTER, CERAMIC (10.7MHz)
X43 1-527-981-00 FILTER, CERAMIC (450KHz)
**************************************************************
TCB
