— 116 —
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
* A-4303-502-A TCB BOARD, COMPLETE
(EXCEPT Malaysia product)
***************************************
(N555AV:AEP,UK)
* A-4303-503-A TCB BOARD, COMPLETE (N555AV:IT,G)
*********************************
* A-4303-514-A TCB BOARD, COMPLETE ( Malaysia product)
***************************************
(N555AV:AEP)
< CAPACITOR >
C1 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C2 1-126-967-11 ELECT 47uF 20% 16V
C3 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C5 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C6 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C8 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C9 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C10 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C11 1-216-295-91 CONDUCTOR, CHIP(2012)(N555AV:IT,G)
C16 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C19 1-163-249-11 CERAMIC CHIP 82PF 5% 50V
(N555AV:AEP,UK)
C21 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C22 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C23 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C24 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C26 1-126-967-11 ELECT 47uF 20% 16V
C28 1-126-967-11 ELECT 47uF 20% 16V
C29 1-162-306-11 CERAMIC 0.01uF 30% 16V
C30 1-124-925-11 ELECT 2.2uF 20% 100V
C31 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C32 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C33 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C34 1-163-091-00 CERAMIC CHIP 8PF 50V
(N555AV:IT,G)
C34 1-163-229-11 CERAMIC CHIP 12PF 5% 50V
(N555AV:AEP,UK)
C35 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C36 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C37 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C39 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C40 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C41 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C42 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C43 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C44 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C45 1-163-038-91 CERAMIC CHIP 0.1uF 25V
C46 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C47 1-126-967-11 ELECT 47uF 20% 16V
C48 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C49 1-124-902-00 ELECT 0.47uF 20% 50V
C50 1-124-903-11 ELECT 1.0uF 20% 50V
C51 1-124-903-11 ELECT 1.0uF 20% 50V
C52 1-126-964-11 ELECT 10uF 20% 50V
C53 1-126-964-11 ELECT 10uF 20% 50V
C54 1-126-157-11 ELECT 10uF 20% 16V
C55 1-126-157-11 ELECT 10uF 20% 16V
C56 1-126-157-11 ELECT 10uF 20% 16V
C57 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C58 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C59 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C60 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C61 1-126-301-11 ELECT 1uF 20% 50V
C62 1-163-141-00 CERAMIC CHIP 0.001uF 5% 50V
C63 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C64 1-126-967-11 ELECT 47uF 20% 16V
C65 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C66 1-126-162-11 ELECT 3.3uF 20% 50V
C67 1-126-933-11 ELECT 100uF 20% 10V
C68 1-162-306-11 CERAMIC 0.01uF 30% 16V
C71 1-162-306-11 CERAMIC 0.01uF 30% 16V
C72 1-126-967-11 ELECT 47uF 20% 16V
C120 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
< FILTER >
CF1 1-579-374-71 FILTER, CERAMIC
CF2 1-760-393-11 FILTER, CERAMIC
CF3 1-760-393-11 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P
< DIODE >
D21 8-719-976-XX DIODE DZH5.1B
D41 8-719-016-74 DIODE 1SS352
< FRONTEND >
FE1 1-233-542-11 FRONT END (4 GANG)
FE2 1-233-514-11 ENCAPSULATED COMPONENT (N555AV:AEP,UK)
FE2 1-239-260-11 ENCAPSULATED COMPONENT (N555AV:IT,G)
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-176-03 IC LA1835
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< JUMPER RESISTOR >
JR1 1-216-295-91 METAL CHIP 0 5% 1/10W
(N555AV:IT,G)
TCB
